RocketFish RF-HTS210 User Manual

ENGLISH 12-0770
9 Grounded LED indicator – lights when a properly grounded AC
outlet is detected. If this LED does not light, we recommend that
you contact a certied, licensed electrician to inspect your
wiring.
10 Energy Savings (ES) Switch – Turn this switch ON to enable
Energy Savings (the master-controlled outlets are shut down
when the the device plugged into the master outlet is turned
o.) When this switch is OFF all outlets are always-on.
11 Coaxial cable surge protection – protects your incoming
coaxial cable line from surges and spikes.
Additional features
• 3,150 joules surge protection – protects your equipment
from damaging power surges and spikes.
• 58 dB EMI/RFI noise ltering – ensures that your equipment
receives only clean power for maximum performance.
• Audible alarm – sounds when the surge protection feature has
reached full capacity and can no longer absorb surges and
spikes. The power manager should be replaced if this alarm
sounds.
• Power cord labels – attach these labels to your power cords
(near the plug end) to help identify which cord is attached to
which device in the event that one should need to be
unplugged for any reason. The labels are pre-printed for
convenience, and the blank labels can be customized for
unique devices.
Operating instructions
1 Plug your power manager’s power cord into a standard 120V AC
outlet. If the LEDs do not light, press the main power
switch/circuit breaker on the front of your power manager.
2 Plug your primary home theater device, such as a TV, into the
Master outlet on your power manager. When you turn o this
device or it goes into sleep or standby mode, the devices
plugged into the Master-controlled outlets automatically shut o
to save power.
Note: This feature is enabled when the Energy Saving (ES) Switch
is in the ON position. If you want all outlets to be always-on, set
this switch to the OFF position.
3 Plug secondary devices, such as a Blu-ray or DVD player, A/V
receiver, or CD player into the Master-controlled outlets on your
power manager
Note: Do not plug devices that you may want to use when the
device plugged into the Master outlet is turned o because
these devices will not receive power.
4 Plug devices that need constant power, such as a DVR/PVR or
devices you want to use when the device plugged into the
Master outlet is turned o, into the Always-on outlets.
5 Connect the incoming coaxial cable source (such as the cable
jack on the wall or incoming satellite line) to the coaxial jack
marked IN on the Power Manager.
6 Connect another coaxial cable to the cable OUT jack on your
power manager and to the cable IN jack on the TV (when not
using a cable or satellite box) or to the cable IN jack on the cable
or satellite or TV (if you do not have a cable/satellite box).
7 After all devices have been properly plugged into the Power
Manager and powered on, when you power the primary device
that is plugged into the Master outlet on and o, the secondary
devices that are plugged into the Master-controlled outlets will
automatically power on and o. Devices that are plugged into
the Always-on outlets will not be controlled by the primary
device, and must be powered on and o separately as desired.
Note: Should the Master-controlled outlets not power on and o
as described when the primary device plugged into the Master
outlet is powered on and o, it is possible that the primary
device draws too much current while in the OFF or STANDBY
mode. In the event this should occur with your equipment, try
plugging a dierent primary device into the Master outlet.
Specifications
• Load rating: 15 amps
• Line voltage: 125V AC @ 60 Hz
• Surge protection: 3 lines (L-N / L-G / N-G)
• Maximum surge current: 165,000 amps
• Maximum energy dissipation: 3,150 joules
• Clamping voltage: L-N / L-G / N-G = 400 volts
• EMI/RFI noise ltering: Up to 58 dB
• Standby power consumption: 0.99 watts
• UL-1449 certied
Safety precautions
• RISK OF ELECTRIC SHOCK–Use only in dry locations and only
indoors.
• DO NOT plug into another relocatable power tap.
• DO NOT daisy chain surge protectors.
• DO NOT use with any aquarium equipment.
• DO NOT use if correctly grounded outlets are not available.
• DO NOT install this device if there is not at least 30 feet
(10 meters) or more of wire between the electrical outlet and
electrical service panel.
One-year limited product warranty
See included warranty sheet, visit www.rocketshproducts.com,
or call 800-620-2790 for additional connected equipment and
product warranty information or for customer service.
© 2012 BBY Solutions, Inc., All Rights Reserved.
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, MN USA 55423-3645
ROCKETFISH is a trademark of BBY Solutions, Inc. All other products and
brand names are trademarks of their respective owners.
