Rockford Fosgate Power Series User Manual

10
SPECIFICATIONS
Specifications subject to change without notice
T1682S
T152S T162S
3-3/4" (94.74mm)
4-21/32" (118mm)
2-13/32"
(61mm)
4-3/64" (102.76mm)
7-5/16" (185.6mm) 5-3/32" (129.6mm)
5-5/64"
(128.95mm)
2-3/4"
(70mm)
5-1/2" (140mm)
4-5/16" (109.6mm)
2-21/32"
(67.3mm)
System Model T152S T162S T1682S
Nominal Diameter - inch (mm) 5-1/4 (133) 6-1/2 (165) 6 x 8 (152.4 x 203.2)
Nominal Impedance (ohms) 4 4 4
Frequency Response 70Hz-22kH 60Hz-22kHz 55Hz-22kH
Sensitivity (SPL@1w/1m) 88dB 89dB 89dB
Power Handling(Watts RMS/Peak) 100 / 200 100 / 200 100 / 200
Mounting Diameter - inch 4-21/32 5-1/2 5-3/32 x 7-5/16
Mounting Diameter - mm 118 140 129.6 x 185.6
Mounting Depth - inch (mm) 2-13/32 (61) 2-21/32 (67.3) 2-3/4 (70)

Rockford Fosgate Power Series Specifications

General

Series	Power
Type	Component
Surround Material	Rubber
RMS Power Handling	100 Watts
Peak Power Handling	200 Watts
Impedance	4-Ohm
Voice Coil Diameter	1.5" (38 mm)
