P1
CONTENTS
CONTENTS..........................................................
CONTROL PANEL ILLUSTRATION.........................
WIRE DIAGRAM...................................................
INSTALLATION....................................................
BASIC OPERATION..............................................
SIRIUS OPERATION.............................................
RADIO OPERATION..............................................
CDC OPERATION..................................................
SPECIFICATION....................................................
TROUBLESHOOTING............................................
AUX/USB/SD OPERATION.....................................
BLUETOOTH OPERATION.....................................
1
2
3
4
5
6-9
10
11-12
13
14
15
16
P16
SPECIFICATION
TUNER(FM)
.....................................................87.5-107.9 MHz
Channel Step.......................................................... 200KHz
Sensitivity ............................................................8dB
Stereo Separation....................................................30dB
Signal to Noise Radio................................................60dB
Frequency Range
TUNER(AM)
....................................................530-1710 KHz
Usable Sensitivity....................................................32 dBuV
Channel Step..........................................................10KHz
Signal to Noise Radio...............................................50dB
Frequency Range
LINE-OUT
Impedance...........................................................33 Ohm
Output..................................................................3 Volt ( max )
GENERAL
..........................................................13.8V DC (10-15.6V allowable)
Speaker Impedance................................................. 4 or 8 ohm
Output Power........................................................... 50W x 4CH
Fuse........................................................................10A
Power Supply
Note: Specifications and the design are subject to possible modification
without notice due to improvement.
