1. Fitting RO
i
400
ROCKINGER
Member of JOST-World
4
ROCKINGER
Member of JOST-World
4
ROCKINGER
Member of JOST-World
22
1.2 Mounting RO
i
400 technical release 1
x Tighten 3, tightening torque 500 Nm
1
(350 Nm
1
by G 135)
x Locate 1 x 2b onto 2a
x Slide 2a and 2b through the bore in 3
x Locate1 x 2b onto 2a and tighten with 2c:
tightening torque 25 Nm
1
x Fit the sealing cap (1) to protect against corrosion.
Note: Before painting, it is essential to close hitch and grease or cover
coupling pin. After painting clean and regrease the coupling pin.
1
Tightening torque, screws are to fix with a torque wrench
at DIN EN ISO 6789, classe A or B
GB
