Rockler Table Saw Small - Parts List; Blade Guard

3
Quantity
1 Sled Body 1
2 MDF Zero Clearance Insert 1
3 Drop-OffRamp 1
4 8-32x1/2"Flat-HeadScrews 2
5 8-32x1"Flat-HeadScrews 3
6 Blade Guard 1
7 1/4"-20CapNut 2
8 1/4"-20x1/2"HexBolt 2
9 Safety Miter Stop 1
10 5-StarKnob 1
11 5/16"-18x1
5
⁄8"Bolt 1
12 8-32x3/4"Screw 2
13 Miter Bar 1
PARTS LIST
Safety Miter Stop must
be used or serious injury
can occur.
Insert will be cut
to size during setup
13
12
1
8
6
7
7
4
3
2
10
9
11
5
