RC821U 1080P Video Conferencing PTZ Camera User Manual
3
Tilt Speed 2.7°~31.5°/s
Image Flip Support
Image Freeze Support
Preset Position 255
Preset Accuracy 0.1°
Network Features
Video
Compression
H.264/MJPEG
Video Stream First Stream, Second Stream
First Stream
Resolution
1920x1080, 1280x720,
1024x576, 960x540, 640x480,
640x360
Second Stream
Resolution
1280x720, 1024x576,
720x576 (50Hz),
720x480 (60Hz),
720x408, 640x360, 480x272,
320x240, 320x180
Video Bit Rate
for First Stream
32kbps~20480kbps
Video Bit Rate
for Second
Stream
32kbps~6144kbps
Bit Rate Control CBR, VBR
Frame Rate
50Hz: 1fps~50fps
60Hz: 1fps~60fps
Audio Type AAC
Audio Bit Rate 96kbps, 128kbps, 256kbps
Protocols
TCP/IP, HTTP, RTSP,
RTMP(S), ONVIF, DHCP,
SRT (MJPEG format is not
supported), Multicast, etc.
USB Features
Operate System
Windows 7/8/10, Mac OS X,
Linux, Android
Color System/
Compression
MJPEG/YUY2/H.264
Video Format
 YUY2: 1080P60 (max.)
 H.264 AVC: 1080P60
(max.)
 MJPEG: 1080P60 (max.)
USB Audio Support
USB Protocol UVC 1.1
UVC PTZ Control Support
Interface
Network
Interface
1 x NET: 10M/100M
Adaptive Ethernet Port
USB Interface 1 x USB 3.0: Type-C
Audio Interface 1 x LINE IN: 3.5mm Interface
Communication
Interface
1 x RS232: 8pin Min DIN; Max.
Distance: 30m; Protocol:
V
ISCA/Pelco-D/Pelco-P
Video Interface 1 x HDMI 1.4b
Power Interface
JEITA type (DC 12V)/
USB Type-C (USB 5V)/PoE
General Specifications
Input Voltage DC 12V/USB 5V/PoE (802.3af)
Input Current
12V 1.0A (max.)
/5V 1.5A (max.)
Operating
Temperature
0°C~40°C
Storage
Temperature
-40°C~60°C
Power
Consumption
12W (max.)
Dimension 142.2 x 151.9 x 177.7 (mm)
Net Weight About 1.5Kg
Product features and specifications are subject
to change without notice.
Note
