Rodec MX1400 - Page 30

30
Music equalizer: - Low: +10dB / -21dB at 100Hz
- Mid: +10dB / -21dB at 1kHz
- High: +10dB / -21dB at 10kHz
Microphone equalizer: - Low: +/- 12dB at 100Hz
- Mid: +/- 12dB at 1kHz
- High: +/- 12dB at 10kHz
Monitor output equalizer: - Low: +12dB / -12dB at 100Hz
- High: +12dB / -12dB at 10kHz
Power supply voltage: 90VAC – 264VAC
Power supply frequency: 47Hz – 63Hz
Power consumption: 38W (On), 60W (Full load), 6W (Stand by)
Operating temperature: 0°C (32°F) – 40°C (104°F)
Operating humidity: 5% - 90% (no condensation)
Mechanical specifications:
Frontpanel dimensions (W x D): 254.0mm (10,0”) x 355.0mm (14,0“) (8HE)
Bottombox dim. (W x D x H): 246,0mm (9,7“) x 343,0mm (13,5“) x 110,0mm (4,3“)
Panel cut out dimensions (W x D): 250,0mm (9,8“) x 347,0mm (13,7“)
Packed box dimensions (W x D x H): 335,0mm (13,2“) x 414,0mm (16,3“) x 207,0mm
(8,1“)
Weight: 4,50kg (9,92lbs)
Packed weight: 5.46kg (12,04lbs)
