Specifications
0dBm = 0.775V RMS
Nominal analogue input levels:
- Line A asymmetrical (RCA): 500mV / 50kΩ
- Line B asymmetrical (RCA): 500mV / 50kΩ
- Phono asymmetrical (RCA gold plated): 5.2mV / 50kΩ
- Microphone (channel 1 – 3) symmetrical (XLR): 9.1mV / 3.6kΩ
- Microphone symmetrical (XLR or ¼” TRS JACK): 4.2mV / 1.8kΩ
- Effects return (1/4” TRS JACK): 775mV / 10kΩ
- Priority in (optional) (RCA): 500mV / 1.5kΩ
Nominal analogue output levels:
- Master asymmetrical (RCA): 775mV / 10kΩ
- Master symmetrical (XLR): 1.55V / 600Ω
- Monitor symmetrical (XLR): 1.55V / 600Ω
- Record asymmetrical (RCA): 500mV / 10kΩ
- Effects send asymmetrical (1/4” TRS JACK): 775mV / 10kΩ
- Headphones (1/4” TRS JACK):
- 8Ω: (1kHz – 1%THD) 417mW (1.8V) / 1.1W music power
- 32Ω: (1kHz – 1%THD) 1.0W (5.7V) / 1.7W music power
- 600Ω: (1kHz – 1%THD) 520mW (17.7V) / 0.6W music power
Digital input:
- Line B (RCA): S/P DIF IEC 958 type II 32kHz – 192kHz
- USB (optional): 32kHz - 48kHz 16bit
Digital output:
- Record (RCA): S/P DIF IEC 958 type II 44.1kHz
- USB (optional): 11.025kHz - 48kHz 16bit
Signal headroom: 20.0dB @ 1kHz / THD < 0.05%
Crosstalk:
- Left to right of an input channel: >60dB @ 1kHz
- Channel to channel: >86dB @ 1kHz
Frequency response: +/- 0.25dB from 20Hz to 20kHz
Subsonic filter: -25dB at 10Hz
Dynamic range: 103dB
Signal to noise ratio: 90dB
Total harmonic distortion: < 0.006%
