RODEC MX180 MKII RODEC MX34
2
- Specifications - 2 -
- Safety instructions - 3 -
- Installation of the mixing panel - 3 -
- Frontpanel, switches and control - 3 -
- Connections - 4 -
- Master output 3V in stead of 1.5V - 5 -
- Operating instructions - 5 -
- Subsonic filter - 6 -
- Remote control option - 6 -
- Pictures on cover - 26 -
SPECIFICATIONS
Inputs Input sensitivity Signal/Noise Ratio Remarks
PHONO 1-4 (8)
AUX 1-4 (8)
CD/DAT 1-4 (8)
MD(VIDEO) 1-4 (8)
MIC 1-4 (8)
symmetrical
MIC DJ symm
assym.
2mV/50kΩ
200mV/100kΩ
200mV/100kΩ
200mV/100kΩ
4.8mV/4kΩ
1.7mV/1.2kΩ
1.2mV/22kΩ
-74dB
-86dB
-86dB
-86dB
-80dB
-83dB
-85dB
RIAA correction
Panoramic control
Equalizer
Outputs
Master 1-2 assym.
Master 1 symm.
AUX
Recording 1-4 (8)
Phones
1.5V(3V)/10kΩ
1.5V(3V)/600Ω
770mV/10kΩ
500mV/10kΩ
10V/600Ω
Subsonic filter
Subsonic filter
Recording out selector
Phones 200-600Ω
- Tone controls: Music: Bass +/-13dB @ 100Hz
Middle +/-13dB @ 1kHz
High +/-13dB @ 10kHz
- Subsonic filter: -25dB @ 10Hz
- Power source: Panels are leaving the factory on: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
- Fuse: T125mA
- Power consumption: OFF=2.2VA ON=16VA
- Approbation: CE-approved
- Dimensions: MX180MKII MX34
Front: 482 x 310 (19” x 7HE) 610 x 310 (24” x 7HE)
Chassis: 444 x 295 x 150 585 x 295 x 150
- Weight: 7.5kg 9.4kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL MX180MKII / MX34
SERIAL NUMBER ……………… (on the back of the set)
Please give model and serial number by every information requested.
Thank you very much for purchasing the RODEC mixing panel MX180MKII / MX34.
This mixing panel is a topline mixing panel, capable of outstanding performance in combination with
high grade systems.
SAFETY INSTRUCTIONS
