FC-200 Series Menu Layout
Power Settings
Power [ 0.0 to 100.0 ] % (amplitude or power setting)
Max Pwr [ 100.0 to 20.0 ] % (maximum power level)
Min Pwr [ 0.0 to 60.0 ] % (minimum power level)
Soft [ 0.0 to 10.0 ] Seconds (soft start time) (Default 0.1)
Pulse Md [ 120, 60, 60 Rev, 40, 30 ] (magnetic pulses per second)
Ext Sig [ CFR, 4-20mA, 0-20mA, 0-5VDC ] (external amplitude input)
LV Comp [ Normal, Disable ] (line voltage compensation)
Pw Curve [ Normal, Linear ] (amplitude power curve slope)
Timer Settings
On Delay [ 0.0 to 25.0 ] Seconds (Default 2.0)
Off Dly [ 0.0 to 25.0 ] Seconds (Default 2.0)
Empty B [ 5 to 240 ] Seconds; (empty bowl timer or jam timer) (Default 10)
Function Settings
Sens Log [ Normal, Inverted ] (sensor logic)
NPN/PNP [ Normal, NPN, PNP ] (sensor output type) Note: Normal uses active input, PNP/NPN.
Run Mode [ Normal, Constant On, 2-Speed, High/Low ] (how sensors control the feeder)
Run Input [ Normal, Disable] (Disable causes the control to ignore the Run Input)
Empty B [ Normal, Enable ] (empty bowl timer reaction)
Aux Out [ Normal, Inverted, Alarm, Alarm Inv, Air Jet ] (auxiliary output logic)
Diagnose Info
Software [ Revision Level ] (software revision level)
I/O Stat [xxxxxxxx ] (factory use)
Security Settings
Keypad [ Unlock, Amp Adj, Lock ] (security limits access to allowable features)
Sec Code [ 00 to 255 ] (security number)
Default Settings
User Restore [ ‘Enter’ Restores User Defaults ] (restores final set-up for feeder)
User Save [ ‘Enter’ Saves User Defaults ] (saves final set-up of feeder)
Factory Restore [ ‘Enter’ Restores Factory Defaults ] (restores as it came from the factory, bold text)
Language Select
Language [ English, Spanish, French, German ] (select desired language)
Normal Display Message Priority
The normal operating display shows the status of the control with regard to input signals and control settings. They are
listed from highest to lowest in priority. The highest priority message takes precedence over all other messages.
OFF The 1/0 button has been pushed to disable control operation.
Stop The run jumper has not been not made.
Full The parts sensor logic is telling the control to stay off.
Empt Empty bowl timer has timed out because parts did not pass by the parts sensor for a certain time.
Ext. An external signal is in control of the speed input.
Low Low Speed used when 2 speed has been selected and the sensor is not made.
0Spd The output is off because the output is set to 0.0%.
CFR The CFR function is operating, and the feeder is running normally.
Run The feeder is running normally.
Sensor Status Messages
S=1 The parts sensor indicates parts are needed.
S=0 The parts sensor indicates parts are not needed.
= The Flashing equal sign indicates the parts sensor is timing prior to changing the output state.
Power Setting Messages
Mn Mn indicates the power setting is at the minimum amplitude.
Mx Mx indicates the power setting is at the maximum amplitude.
FC-200 Menu.doc 3/22/2011
Press “Back” key to exit menu.
Main Menu
Sub Menu
Normal Operation Display
Press ‘Enter’ to enter program menu
or get to the security menu.
Use the arrow UP and DOWN keys
to adjust the security number. Press
enter to test the security number.
Control Setting Adjustments
