User Manual P14
Stacking Installation
1. Base Bar connection with Base Truss
Connect the Base Bar and Base Truss by Pin and Safely Clip.
2. Rear Support Truss and Rear Bridge installation
Lock of Base Truss
Adjust the Knob and make sure the Base Truss
and Base Bar in same horizontal
Half Coupler and Screw
Knob
(Adjusting height)
Universal Adjusting Footpad
(Keep the Base Bar always horizontal )
Plate
(Fix the Base Truss on the ground )
