ROE BP3 User Manual

Accessories
04
User Manual P10
Name
SAP No.
Dimension
Weight
Evision
201000S0007
W480×H45×D240mm
2.30kg
:
:
:
:
Name
SAP No.
Dimension
Weight
Max Length
Data Cable
208004S0242
30m
1.42kg
100m
:
:
:
:
:
Name
SAP No.
Dimension
Max.
Capacity
Flightcase
309003-00106
W1165×H835×D617mm
8 tiles of BP
:
:
:
:
Name
SAP No.
Dimension
Weight
Max Current
Power Cable
208001S0754
10m
1.60kg
16A
:
:
:
:
:
Name
SAP No.
Data Cable
201000S0243
:
:
Dimension
Weight
0.75m
0.16kg
:
:
Name
SAP No.
Data Cable
208004S0244
:
:
Dimension
Weight
0.35m
0.08kg
:
:
Name
SAP No.
Dimension
Weight
Power Cable
208001S0862
0.35m
0.1kg
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Max loading
Max loading of tiles
Hanging Bar
207002S0046
W494×H158×D205mm
4.50Kg
Aluminium 6063
20945N(safe factor 5)
Max loading/5/weight of tile≈20 tiles
:
:
:
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Max loading
Max loading of tiles
Hanging Bar
207002S0047
W94×H158×D205mm
7.70Kg
Aluminium 6063
16295N(safe factor 5)
Max loading/5/2/weight of tile≈17 tiles
:
:
:
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Stacking Bar
207002S0057
W494×H60×D135mm
7.90Kg
Aluminium 6063
:
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Stacking Bar
207002S0058
W994×H60×D135mm
11.87Kg
Aluminium 6063
:
:
:
:
:
Name
SAP No.
Dimension
Max.
Capacity
Flightcase
309003-00106
W1165×H835×D617mm
8 tiles of BP
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Base Truss
304012-00503
W1000×H290×D50mm
7.40Kg
Aluminium 6063
:
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Rear Support Truss
304012-00504
W1000×H290×D50mm
4.35Kg
Aluminium 6063
:
:
:
:
:
Name
SAP No.
Dimension
Weight
Material
Rear Bridge
206002S0178
W182×H133×D35mm
0.93Kg
Aluminium 6063
:
:
:
:
:
