3 Product description
The B70/1DC controller is a unit for the SENSORED control, with a high resolution encoder, of a ROGER brushless motor
for automated sliding gates.
Ensure that the parameter $ is set correctly. If this parameter is not set correctly, the automation system
may not function properly.
ROGER TECHNOLOGY cannot be held responsible for any damage or injury due to improper use or any use other than
the intended usage indicated in this manual.
<J WJHTRRJSI ZXNSL TSQ^ 74,*7 9*(-3414,> FHHJXXTWNJX FSI HTSYWTQ FSI XFKJY^ IJ[NHJX 8UJHNܪHFQQ^ \J
recommend installing F4ES or F4S series photocells.
For further information, refer to the installation manual of the BH30 or BM30 automation system.
4 Updates of version P2.35
1. Fine-tuned the stroke programming procedure.
2. Optimised the management of the parameters when they are changed by B74/BCONNECT.
3. Improved the management criterion for battery operation; adjusted the battery voltage thresholds (par.) combined with the use
TK'5'=
5 Technical characteristics of product
BH30/603
BH33/604
BH30/803
BH30/804
BH30/503/HS
BH30/504/HS
BH30/603/HS
BH30/604/HS
BM30/400 BM30/300/HS
BH30/804/R
MAINS POWER VOLTAGE 230 V~ ± 10% 50 Hz (B70/1DC/115: 115 V~ ± 10% 60 Hz)
MAXIMUM MAINS POWER ABSORPTION 130 W 140 W 140 W 120 W 125 W
140 W
INRUSH POWER 300 W 450 W 350 W 280 W 320 W
330 W
FUSES
F1 = 15A (ATO257) motor power circuit protection
F2 = 2A (ATO257) accessories power supply protection
F3 = T2A (5x20 mm) primary transformer protection
CONNECTABLE MOTORS 1
MOTOR POWER SUPPLY 24 V~, with self-protected inverter
MOTOR TYPE sinusoidal drive brushless (ROGER BRUSHLESS)
MOTOR CONTROL TYPE XJSXTWJIܪJQITWNJSYJIHTSYWTQ+4(
RATED MOTOR POWER 45 W 75 W 120 W 45 W 100 W
110 W
MAXIMUM MOTOR POWER 125 W 200 W 350 W 110 W 320 W
330 W
MAXIMUM POWER,
FLASHING LIGHT
13 W
(24V
)
25 W (24V )
13 W
(24V )
25 W (24V )
FLASHING LIGHT DUTY CYCLE 50%
COURTESY LIGHT POWER 100 W 230 V~ - 40 W 24 V~/dc (potential free contact)
GATE OPEN LIGHT POWER 3 W (24 V
)
MAXIMUM ACCESSORY
CURRENT ABSORPTION
7 W
(24V
)
10 W (24V )
7 W
(24V )
10 W (24V )
OPERATING TEMPERATURE
-20°C +55°C
SOUND PRESSURE DURING USE <70 dB(A)
PRODUCT DIMENSIONS dimensions in mm 200x90x45 weight: 0,244 kg
(1)
BH30/500/HS/115 - BH30/600/115 - BH30/600/HS/115 - BH30/800/115 - BH30/804/R/115 -
BM30/300/HS/115
The total of the absorption values of all the accessories connected must not exceed the maximum power
values shown in the table. The values are guaranteed with original ROGER TECHNOLOGY accessories ONLY.
The use of non-original accessories may lead to malfunctioning. ROGER TECHNOLOGY declines all responsibility for
incorrect or non-conforming installations.
All the connections are protected by fuses (refer to the table). The courtesy light requires an external fuse.
