13 Parameters menu
PARAMETER
PARAMETER
VALUE
$ 
Selecting automation system model
WARNING! If this parameter is not set correctly, the automation system may not function properly.
N.B.: in the event of a reset to restore the default parameters, this parameter must be set again manually.

BH30/603 - IRREVERSIBLE motor for gate leaves up to 600 kg
BH30/604 - IRREVERSIBLE motor for gate leaves up to 600 kg

BH30/803 - IRREVERSIBLE motor for gate leaves up to 1000 kg
BH30/804 - IRREVERSIBLE motor for gate leaves up to 1000 kg

BH30/503/HS - BH30/504/HS - IRREVERSIBLE HIGH SPEED motor for gate leaves up to 600 kg
BH30/603/HS - BH30/604/HS - IRREVERSIBLE HIGH SPEED motor for gate leaves up to 600 kg
(see chapter 14 "Special parameters for High Speed series")

BM30/400 - IRREVERSIBLE motor for gate leaves up to 500 kg

BM30/300/HS - IRREVERSIBLE HIGH SPEED motor for gate leaves up to 400 kg
(see chapter 14 "Special parameters for High Speed series")

BH30/804/R - REVERSIBLE motor for gate leaves up to 800 kg
(see chapter 15 "Special parameters for High Speed series")
$ 
Automatic closure after pause time (from gate completely open)

Disabled.

From 1 to 15 of gate closure attempts after photocell is triggered.
Once the number of attempts set is reached, the gate remains open.

9MJLFYJYWNJXYTHQTXJNSIJܪSNYJQ^
$ 
Automatic gate closing after mains power outage

Disabled. The gate does not close automatically when mains power is restored.

Enabled. If the gate is NOT completely open, when mains power is restored, the gate closes after a 5 second warning
XNLSFQQJI\NYMYMJܫFXMNSLQNLMYNSIJUJSIJSYQ^TKYMJ[FQZJXJY\NYMYMJUFWFRJYJW$). The gate closes in “position
recovery” mode (see chapter 20).
$ 
Selecting step mode control function (PP)

Open-stop-close-stop-open-stop-close...

Condominium function: the gate opens and closes after the set automatic closing time.
The automatic closing timer restarts if a new step mode command is received.
Step mode commands are ignored while the gate is opening. This allows the gate to open completely and prevents the
gate from closing when not required.
If automatic closing is disabled ($ ), the condominium function automatically attempts a closing manoeuvre $ .

Condominium function: the gate opens and closes after the set automatic closing time.
The automatic closing timer does NOT restart if a new step mode command is received.
Step mode commands are ignored while the gate is opening. This allows the gate to open completely and prevents the
gate from closing when not required.
If automatic closing is disabled ($ ), the condominium function automatically attempts a closing manoeuvre $ .

Open-close-open-close.

Open-close-stop-open.
D 
5WJܫFXMNSL

)NXFGQJI9MJܫFXMNSLQNLMYNXFHYN[FYJIIZWNSLTUJSNSLFSIHQTXNSLRFSTJZ[WJX

Flashing warning signal for 1 to 10 seconds prior to every manoeuvre.

XJHTSIܫFXMNSL\FWSNSLXNLSFQUWNTWYTHQTXNSLRFSTJZ[WJ
D 
Condominium function for partial open command (PED)

Disabled. The gate opens partially in step mode: open-stop-close-stop-open...

Enabled. Partial commands are ignored during gate opening.
