18.1 B74/BCONNECT mode
By inserting B74/BCONNECT in the WIFI connector, all the functions are managed through internet browser and
devices such as smartphones, tablets, PCs, exploiting WiFi communication, tablet, PC, all the functionalities of the
central unit are managed, using the WiFi communication.
For further information consult the installation manual of the connection module B74/BCONNECT
connection module.
Remote assistance" mode
Allows access and therefore the management of all the data of the control unit only in cloud mode and therefore with
remote management.
When remote assistance is enabled, the message ASCC (assistance connect controlled) appears on the display.
By pressing the TEST button this message disappears for 10 seconds, and it is possible to access the parameters
and other functions of the display.
&KYJW  RNSZYJXYMJ INXUQF^ LTJXNSYTXYFSIG^ NKYMJINXUQF^ NXF\FPJSJI G^ UWJXXNSLF PJ^ YMJܫFXMNSL &8((
reappears.
"Emergency operation" mode
This mode is used to exclude motor and safety alarms (e.g. photocells and sensitive edges), allowing the automation
to open and close at low speed and with the operator present, with movement of the leaves only in the presence of a
persistent command (when the command is released, the leaves stop).
*RJWLJSH^TUJWFYNTSNXNSINHFYJIG^FHYN[FYNTSTKYMJܫFXMNSLQNLMYFYFMNLMJWKWJVZJSH^
Two types of "emergency" mode are possible: residential or condominium.
1) residentialܫFXMNSLL-ES display indication): the PP command (from the terminal board or radio control) is initially
managed as an opening command; only when complete opening has been reached will activation of the command
send it to closing. Only when complete closure has been achieved will the command be able to open again.
2) condominiumܫFXMNSL1*2INXUQF^NSINHFYNTSYMJ55HTRRFSINXNSNYNFQQ^RFSFLJIFXFSTUJSNSLHTRRFSI
but once it has been fully opened the leaves no longer close.
In this mode the display stand-by is not activated, always indicating the mode in progress.
By pressing the TEST button this message disappears for 10 seconds, and it is possible to access the parameters
and other functions of the display.
ASCC "Remote assistance" mode enabled
L-ES "Residential emergency operation" mode enabled
L-EM "Condominium emergency operation" mode enabled
19 Mechanical release
In the event of a fault or mains power loss, the gate may be released and opened manually. For systems with
BH30/804/R the gate can be moved by hand without unlocking it.
If the gate releases with the controller unit powered, the message 6WRSܫFXMJXTSYMJINXUQF^
For further information, refer to the locking/release operation in the manual of the BH30 or BM30 automation
system.
• When the release system is restored to the normal operating position, if the gate is not completely open or completely
closed the next time a command is received, the control initiates a position recovery procedure (see chapter 20).
• Activating one of the two limit switches immediately reacquires the position.
20 Position recovery mode
After a mains power outage or after mechanically releasing the gate, if the gate is not completely open or completely
closed the next time a command is received, the control initiates a position recovery procedure:
• The gate starts a low speed manoeuvre.
• 9MJܫFXMNSLQNLMYܫFXMJX\NYMFINKKJWJSYIZY^H^HQJYMFSSTWRFQXTSXTKK
• The control unit recovers the installation data during this procedure. Warning! During this procedure, do not use any
controls until one of the two limit switches is reached.
• Activating one of the two limit switches immediately reacquires the position.
