21 Initial testing
9MJYJXYNSLRZXYGJUJWKTWRJIG^VZFQNܪJIYJHMSNHFQUJWXTSSJQ
The installer is required to measure impact forces and select on the control unit the appropriate speed and
YTWVZJ[FQZJXYTJSXZWJYMFYYMJRTYTWNXJIITTWTWLFYJWJRFNSX\NYMNSYMJQNRNYXIJܪSJIG^YMJXYFSIFWIX*3
and EN 12445.
Make sure that the provisions in Chapter 1 "GENERIC WARNINGS are observed.
• Turn on the power supply.
• Check that all connected controls are working correctly.
• Check that the release handle works correctly. The message 6W23RZXYܫFXMTSYMJINXUQF^
• Check travel and deceleration.
• Check that the impact force is correct, in compliance with EN 12453 and EN12445.
• Check that the safety devices are activated correctly.
• If the battery kit is installed, disconnect from mains and check that the batteries are working.
• Disconnect from mains power and disconnect the batteries (if used), then reconnect. Starting with the gate stopped
in an intermediate position, check that the position recovery procedure is completed correctly for both the open and
closed positions.
• Check that the limit switches are set correctly and function correctly. Adjust the position of installation of the motor
if necessary.
• Check that there is a gap of at least 2-3 cm between the gate and the mechanical stop at the end of the manoeuvre.
• Only for BH30/804/R. Check that without mains or battery voltage, when moving the leaf by hand, the control unit
is switched on and that the display shows the "6(/)" message.
• Only for BH30/804/R. If there are batteries, disconnect the mains power and check that the display shows E$WW. If
6(/) is displayed followed by $/,
, change the red and black cables connection to the POWER-IN terminal strips,
FXNSINHFYJINSܪL
22 Start-up
9MJNSXYFQQJWNXWJVZNWJIYTIWF\ZUFSIUWJXJW[JYMJYJHMSNHFQܪQJTKYMJX^XYJRKTWFYQJFXY^JFWX\MNHMRZXY
contain the wiring diagram, the drawing and the photo of the system, the risk analysis and the solutions adopted, the
manufacturer's declaration of conformity for all connected devices, the instructions manual of each device and / or
accessory and the system's maintenance plan.
Apply a plate indicating the automation system data on the motorised door or gate, the name of the person in charge
of the start-up, the serial number and the year of construction, as well as the CE mark.
Apply a plate and / or label with the indications for the operations required to manually unlock the system.
Draw up and provide the end user with the declaration of conformity, instructions and warnings for use and the
maintenance plan.
Make sure that the end user has understood the correct automatic, manual or emergency operation of the system.
Inform the end user about the dangers and risks that may be present.
23 Maintenance
Perform scheduled maintenance every 6 months.
Check cleanliness and function.
If the unit contains dirt, moisture, insects or other foreign matter, disconnect from mains power and clean the board
and the housing.
Repeat the initial installation test procedure after cleaning.
If any corrosion is found on the printed circuit board, evaluate if it is necessary to replace the board itself.
Check that the battery is in good working order.
24 Disposal
9MNXUWTIZHYRF^ TSQ^ GJZSNSXYFQQJIG^VZFQNܪJIYJHMSNHFQUJWXTSSJQKTQQT\NSLXZNYFGQJUWTHJIZWJXKTW
removing the product correctly and safely. This product consists of numerous different materials. Some of
YMJXJRFYJWNFQXRF^GJWJH^HQJI\MNQJTYMJWXRZXYGJINXUTXJITKHTWWJHYQ^FYYMJXUJHNܪHWJH^HQNSLTW
waste management facilities indicated by local legislation applicable for this category of product. Do not
dispose of this product as domestic refuse. Observe local legislation for differentiated refuse collection, or
hand the product over to the vendor when purchasing an equivalent new product.
1THFQQJLNXQFYNTSRF^JS[NXFLJXJ[JWJܪSJXKTWYMJNSHTWWJHYINXUTXFQTKYMNXUWTIZHY
Warning! Some parts of this product may contain substances that are harmful to the environment or dangerous and
which may cause damage to the environment or health risks if disposed of incorrectly.
