1 INSTALAREA STANDARD SERIA R20 • STANDARD INSTALLATION R20 RANGE • ANLAGETYP SERIE R20 •
INSTALLATION TYPE SÉRIE R20 • INSTALACIÓN TIPO SERIE R20 • SISTEMA DO TIPO SÉRIE R20
DESCRIERE
DESCRIPTION
BESCHREIBUNG
DESCRIPTION
DESCRIPCIÓN
DESCRIÇÃO
1
Automatizare R20
Automatism R20
Automatisierung R20
Automatisme R20
Automatismo R20
Automatismo R20
2
Unitatea de comandă
Control panel
Steuerung
Centrale de commande
Central de mando
Central de comando
3
Selector cu cheie
Key selector
Schlüsseltaster
Sélecteur à clé
Selector de llave
Selector de chave
4
Lampă de semnalizare
Flashing light
Blinkleuchte
Clignotant
Luz intermitente
Lampejante
5
Antenă
Antenna
Antenne
Antenne
Antena
Antena
6 Fotocelula externă External photocell Externe Lichtschranke
Cellule photoélectrique
externe
Barrera fotoeléctrica
exterior
Sensor fotoelétrico
externo
7 Fotocelulă internă Internal photocell Interne Lichtschranke
Cellule photoélectrique
interne
Barrera fotoeléctrica
interior
Sensor fotoelétrico
exterior
8
Opritor mecanic la
deschidere
Gate open mechanical
stop
Mechanische Feststell-
vorrichtung beim Öffnen
Butée mécanique en ou-
verture
Tope mecánico de aper-
tura
Retentor mecânico em
abertura
2 DIMENSIUNI • DIMENSIONS • AUSSENMASSE • DIMENSIONS • DIMENSIONES • DIMENSÕES
5x0,5-RX
5x0,5-RX
3x0,5-TX
3x0,5-TX
R20/300
R20/302
R20/3115
R20/300
R20/302
R20/3115
R20/500
R20/502
R20/500
R20/502
165 mm120 mm
320 / 520 mm
858.5 mm / 1088.5 mm
= 320 mm
= 520 mm
= 858.5 mm
= 1088.5 mm
