Technical Specification
Parameter Value
Supply 10...16 VDC
Current consumption Avg. 25 mA @ 12V DC,
Max. 80 mA @ 16V DC with relay output active
Anti-sabotage protection (Tamper) NC contact, 50mA/24V
Environmental Class (according to EN 50131-
1)
Class IV, Outdoor-General,
Temp.: -25°C +60°C
Relative humidity: 10 - 95% (non-condensing)
Ingress protection IP65
Connection cable length (for SL2000F-VP) 45cm
Dimensions 100 X 40 X 25
Weight ~ 150g
Approvals CE
Connection Terminals Assignments
Label Wire colour Description
+12V Red Supply input plus
GND Black Supply input minus
Status Output Green Status transistor output, max. current sink 1.0A/16V DC
AUX Brown Aux transistor output, max. current sink 1.0A/16V DC
TMP A Grey Tamper contact A, NC max. 50mA/24V
TMP B Yellow Tamper contact B, NC max. 50mA/24V
Exit Button Blue Exit Button input, NO type
Door Contact White-Green Door Contact input, NO type, 1.5A/24V DC/AC
LED SYSTEM Pink
NO input, when shorted with supply minus LED SYSTEM
becomes active
COMM White Door Relay output, COMMON contact, 1.5A/24V DC/AC
NO Violet Door Relay output, NO contact, 1.5A/24V DC/AC
NC Grey-Pink Door Relay output, NO contact, 1.5A/24V DC/AC
Reset Brown-Yellow User for memory reset
