Technical Specification
Parameter
Value
Supply
10...15 VDC
Current consumption
Avg. 25 mA @ 12V DC,
Max. 80 mA @ 15V DC with relay output active
Anti-sabotage protection (Tamper)
NC contact, 50mA/24V
Environmental Class
SL2000F-VP: Class IV, outdoor-general, temp.: -25°C
+60°C, relative humidity: 0 - 95%
SL2000F: Class I, indoor, temp. +5°C- +40°C, relative
humidity: 0 - 95% (without condensation)
Connection cable length (for SL2000F-VP)
45cm
Dimensions
115 X 80 X 35 mm
Weight
SL2000F: ~ 90g
SL2000F-VP: ~ 450g
Approvals
CE
Connection assignments
Label
Terminal
number for
SL2000F
Wire colour for
SL2000F-VP
Description
+12V
1
Red
Supply input plus
GND
2
Black
Supply input minus
TMP A
3
Grey
Tamper contact A, NC max. 50mA/24V DC/AC
TMP B
4
Yellow
Tamper contact B, NC max. 50mA/24V DC/AC
IN1
5
Blue
Exit Button input, NO type
IN2
6
Red-Blue
Door Contact input, NO type, 1.5A/24V DC/AC
SYS
7
Pink
LED SYSTEM input, NO type
OUT1
8
Green
Transistor output, max. current sink 50mA/15V DC
OUT2
9
Brown
Transistor output, max. current sink 50mA/15V DC
REL1-COM
10
White
REL1 output, COMMON contact, 1.5A/24V DC/AC
REL1-NO
11
Violet
REL1 output, NO contact, 1.5A/24V DC/AC
REL1-NC
12
Grey-Pink
REL1 output, NC contact, 1.5A/24V DC/AC
Ordering Information
Item
Description
SL2000F
Dark grey plastic enclosure, screw connection terminals, indoor installation only
SL2000F-VP
Vandal proof, metal front cover and keys, silver color, pig tail connection cable,
outdoor installation available
