Français
DFX-15 / DFX-40 / DFX-80 / DFX-150
Batt. Full
Batt. Chg
Model. No
Röhr Logo
Volt. Disp
Processor. Act
Dsgn. JK
INTELLIGENT BATTERY CHARGER
The light will
turn green when
fully charged
The light is yellow whilst charging
MICRO PROCESSOR CONTROLLED
12VDC 1.5A
01. Prise secteur
02. Câble d’alimentation
03. Pince positive
04. Pince négative
05. Témoin lumineux de mise sous tension
DFX-15
01
02
03
04
05
