English
DFX-15 / DFX-40 / DFX-80 / DFX-150
Batt. Full
Batt. Chg
Model. No
Röhr Logo
Volt. Disp
Processor. Act
Dsgn. JK
INTELLIGENT BATTERY CHARGER
The light will
turn green when
fully charged
The light is yellow whilst charging
MICRO PROCESSOR CONTROLLED
12VDC 1.5A
01. Mains plug
02. Power cable
03. Positive clamp
04. Negative clamp
05. Power indicator light
DFX-15
01
02
03
04
05
