20
23
Attaching the winch
string to the elevator
1. Guide the string from the cable guide up and
over pulleys marked "A" and "B".
2. Guide string down and under pulley marked "C".
3. Guide string back up to the pulley marked "D".
4. Guide string back down to the string block
marked "E", and slip the knotted end of the
string into the block as shown.
A.
B.
C.
D.
E.
final assembly
