27
27
11
12
Feed the x2 onto your gantry crane
Remove half beam assembly (as shown).
T
ur
n X2 upside down (as shown).
Using the ROK Star Controller
directional wheel, pr
ess forwar
d
and feed X2 onto Gantry Crane.
Replace half beam assembly (as shown).
