Item Part Number Name Description Qty
1 108023 Live Side Housing 1
2 108024 Compression Spring 1
3 108025 Lever Arm 1
4 108026 Locking Nut 2
5 108027 Actuating Pin 2
6 108028 Back Plate 1
7 108029 Dead Side Housing 1
8 108030 Dead Side Puck 1
9 108031 Flat Head Screw 1
10 108032 Hex Head Bolt 2
11 108033 Live Side Puck 1
12 108002 Caliper Assembly 1
13 100788 Brake Spring 1
14 100509 Brake HH Bolt 1/4-28 x 3/4 Hole for Cable 1
15 100169 Nut 1
16 100202 Washer 5/16 4
17 108982 Castle Nut 1
18 101673 Cotter Pin 1
19 100481 Brake Puck Set Includes 108030 & 108033 1
20 108002 Brake Caliper Assy. Includes everything except 13
21 100254 Washer 1/4 1
Brake
Section 10 Continued
1
6
11
7
4
168
13
3
5
2
18
10
17
5
16
15
21
14
25
16
ROKON INTERNATIONAL, 50 Railroad Ave., Rochester, New Hampshire 03839, U.S.A. Copyright 2004
