Item Part Number Name Description Qty
1 105064 Front Fork Weldment 1
2 100453 Front Fender 1
3 100935 Pop Rivet 5
4 103136 Snap Ring 1
5 100772 Bearing Sealed 2
6 107026 Upper Fork Bolt Use Locktite 242 1
7 107025 Lower Fork Bolt Use Locktite 242 1
8 100573 Wheel Adjuster Bolt HH Bolt 3/8-24 x 1 3/4
Fully Threaded 2
9 100036 Nut Hex Nut Jam 3/8-24 2
10 100427 Front Mud Flap 1
11 108106 Front Chain Guard 1
12 101629 Stud 1
13 101630 Receptacle 1
14 100035 Screw Pan Head Screw 10-32 x 1 1/2 2
15 100037 Nut Hex Nut Self Lock 10-32 2
16 100167 Bolt 1/4-28 x 1/2 HH Bolt 1
17 100169 NutLock Nut 1/4-28 1
Front Fork
1
5
6
11
12
13
5
7
9
8
9
8
10
3
16
17
14
15
4
Section 10 Continued
34
ROKON INTERNATIONAL, 50 Railroad Ave., Rochester, New Hampshire 03839, U.S.A. Copyright 2004
