Item Part Number Name Description Qty
1 105066 Frame 1
2 108243 Rear Fender Kohler 1
3 108994 Fairing LHS 1
4 108995 Fairing RHS Front 1
5 108996 Fairing RHS Rear 1
6 100386 Kickstand 1
7 100223 Kickstand Spring 1
8 100285 Clevis Pin 5/16" x 1 3/8" 1
9 100290 Cotter Pin 1/8" x 3/4" 1
10 108272 Foot Rest RHS Cleated 1
11 108271 Foot Rest LHS Cleated 1
12 100343 Passenger Foot Rest (Set of 2) 1
13 101572 Rubber Chain Guard 1
14 101629 Stud for Fairing 6
15 101630 Receptacle for Fairing 6
16 100126 Bolt 1/4-20 x 5/8 HH Bolt 2
17 100255 Washer 2
18 100573 Wheel Adjuster Bolt 2
19 100036 Nut 3/8-24 Jam 2
20 108087 Rear Fender Honda not shown 1
21 100273 Bolt Pan Head Screw 10-32 x 1/4 6
22 100275 Lock Washer Lock Washer #10 6
23 100034 Screw Pan Head Screw 10-32 x 1/2 2
24 100037 Nut Hex Nut Self Lock 10-32 2
25 108123 Bolt HHCS gr 5 5/16-24X 1 1/2 ZN 2
26 100551 Nut Locknut 5/16-24 Hex 2
Frame
Section 10 Continued
33
ROKON INTERNATIONAL, 50 Railroad Ave., Rochester, New Hampshire 03839, U.S.A. Copyright 2004
