Item Part Number Name Description Qty
1 KOH PA911512 6.6 Hp Kohler Command PS 1
2 KOH PA911513 6.6 Hp Kohler Command ES not shown 1
3 100369K Spark Plug 1
4 KOH6308306-S Air Filter 1
5 108235 Throttle Bracket 1
6 108253 E Clip 1
7 108254 Screw M4 Size, 6 mm length .7mm pitch 1
8 108246 Choke Bracket 1
9 108256 Cable Holder 1
10 100034 Screw Pan Head Screw 10-32 x 1/2 1
11 100037 Nut Hex Nut Self Lock 10-32 1
12 100165 Washer Washer #10 flat 1
13 100884 Rear Driven Pulley 1
14 100885 Torque Converter Drive Pulley 1
15 108137 Drive Belt 1
16 108123 Clutch Bolt 1
17 108983 Locking Clip 1
18 KOH6304121-S Exhaust Gasket 1
19 KOH6334005-S Key Crank 1
20 KOH6385304-S Carburetor Complete not shown separately
21 KOH6375704-S Carburetor Repair Kit not shown
22 KOH Air Box Assy Kohler Air Box Assembly not shown separately
23 108968 Nylon Snap In Plug 1
Kohler Engine
Section 10 Continued
31
