Transmission
in Sequence
Item Part Number Name Description Qty
1 101502 Transmission Casting Machined 2 halves 1
2 101523 Oil Seal 5
3 103142 Shaft Front Output 1
4 103134 Snap Ring 2
5 100158 Bearing 8
6 103136 Snap Ring 6
7 100160 Miter Gear 2
8 100045 Roll Pin 3/16" x 1 1/4" 2
9 101519 Spacer 1
10 100043 Woodruff Key #9 3
11 101506 Key #3 3
12 103143 Shaft Rear Output 1
13 101517 Gear 64T Drive 1
14 105082-2 End Cap 1
15 101511 Spacer 1
16 101637 Roll Pin 3/32" x 1/2" 2
17 101633 Gear Selector 1
18 101634 Shift Rod 1
19 101632 Selector Shaft 1
20 101528 Spring 1
21 101527 Ball 1
22 101530 Spacer 1
23 101541 Shift Knob 1
24 101631-3 Gear 40T 1
25 101631-2 Gear 51T 1
26 101631-1 Gear 60T 1
27 101516 Gear 32T 1
28 107039 Shaft Input 1
29 101505 Snap Ring 1
30 101548 Key Straight Cut 1
31 101510 Spacer 1
32 100047 Roll Pin 3/16" x 1" 1
33 101509-3 Gear 40T 1
34 101509-2 Gear 29T 1
35 101509-1 Gear 20T 1
36 100163 Plug 2
37 101525 Screw 1/4"-20 X 1" 1
38 101524 Screw 1/4"-20 X 1 3/4" 1
39 101939 Dowel Pin 2
40 105082 End Cap 1
41 108987 Pressure Relief Valve 1
42 101615 Shim .005 1
43 100163 Plug 2
49
Section 10 Continued
