Item Part Number Name Description Qty
1 101680 Transmission Case Assembly Three Speed 1
2 100039 Lock Washer 5/16 6
3 100038 Screw 5/16-18 x 7/8 5
4 100307 Snap Ring 2
5 108079 Drive Shaft Four Stroke Models 1
6 100314 Drive Line Bearing 1
7 100252 Screw 1/4-20 x 1/2 2
8 100281 Lock Washer 1/4 2
9 100043 Drive Line Key #9 Woodruff 1
10 108054 Universal Joint 1
11 100046 Roll Pin 3/16 x 1 1/2 3
12 100100 Miter Box Assembly Front All Models 1
13 100312 Bearing Retainer Drive Line Support 1
14 100047 Roll Pin 3/16 x 1 1
15 101655 Drive Line Boss 2
16 101656 Retaining Pin 1
17 100002 Override Spring 1
18 101529 Screw HH Bolt 5/16-18 x 2 1/4 1
19 100045 Roll Pin 1
20 101640 Drive Line Assembly 1
Transmission
to Miter Box
51
Section 10 Continued
1
2
18
15
11
11
17
3
2
4
5 14 10
12
13
9
19
3 2
6
16
3 2
8
7
8
7
ROKON INTERNATIONAL, 50 Railroad Ave., Rochester, New Hampshire 03839, U.S.A. Copyright 2004
