Making connections
16
Working with a computer or sequencer
If you want to use the AX-Synth as Master keyboard for
recording applications that involve a computer with
sequencing software, or take advantage of the
“AX-Synth Editor” software, here is the most useful con-
nection system:
Note: The AX-Synth is not multitimbral.
Using headphones
The AX-Synth has one jack for plugging in headphones.
This allows you to play without having to worry about
bothering others around you, even at night.
(1) Plug the headphones into the [PHONES] jack
located on the AX-Synth’s rear panel.
Note: Use stereo headphones. Please use only Roland
headphones. Headphones from other manufacturers may
be unable to provide sufficient volume.
(2) The headphone volume can be adjusted with the
[VOLUME] knob.
Some notes on using headphones
•To prevent damage to the cord, handle the head-
phones only by the headset or the plug.
• Connecting headphones when the volume of con-
nected equipment is turned up may result in damage
to the headphones. Lower the volume on the
AX-Synth before plugging in the headphones.
• Listening at excessively high volume levels will not
only damage the headphones, but may also cause
hearing loss. Use the headphones at a moderate vol-
ume level.
USB port
USB port
AX-Synth (transmits MIDI
messages)
Computer or sequencer
(records and transmits
MIDI messages)
Module, synthesizer, etc. (receives MIDI messages)
(Not necessary when you are using the “AX-Synth Editor” software.
MIDI OUT
MIDI IN
AX-Synth_e2 Page 16 Monday, October 12, 2009 3:41 PM
