Roland FA-06 Service Notes

17
Feb. 2014 FA-06
5100029775 LED (INFRARED) L-7113F3C(F) 1
00127367 LED (RED/GREEN) SPR-39MVW 1
5100030358 DIODE PT334-6B 1
DIODE
POTENTIOMETER
5100007846 ROTARY POT(231-09034-01-00) XV09213YNPV25F1B10K/D 7
5100004183 POTENTIOMETER(231-08052-02-00 RK12L12C0A04 50KBX2 25MM 1
04901712 ROTARY POT. RK09K1110D4S 1
03122134 ROTARY ENCODER EC12E2420802 1
CONNECTOR
04784856 CARD CONECTR AXA2R63361TJ 610-07014-08-00 1
WIRING, CABLE
# 5100036240 CA ASSY 26WAY 240+240MM W/3 HEADER 1
# 5100036252 WIRING W1 (AUDIO) 1
# 5100036242 WIRING W2 (MIDI) 1
# 5100036247 WIRING W3 (PANEL AD) 1
# 5100036241 WIRING 1061#28 3X300-PHR-PHR-F 1
# 5100037064 WIRING 1061#28 4X50-PHR-PHR-F 1
# 5100038580 WIRING 1061#28 6X80-PHR-PHR-F 1
# 5100036243 WIRING 1061#28 7X350-PHR-PHR-F 1
# 5100036245 WIRING 1061#28 8X820-PHR-PHR-F 1
# 5100036246 WIRING 1061#28 9X490-PHR-PHR-F 1
# 5100036248 WIRING 1061#28 10X100-PHR-PHR-F 1
# 5100036250 WIRING 1061#28 11X710-PHR-PHR-F 1
# 5100036251 WIRING 1061#28 12X580-PHR-PHR-F 1
# 5100036253 WIRING 1061#28 15X700-PHR-PHR-F 1
# 5100036254 WIRING 1061#28 16X350-PHR-PHR-F 1
# 5100036237 FLAT CABLE SML2CD-12X80-BDX8(BL)-P1.0-S4 1
# 5100036239 FLAT CABLE SML2CD-16X140-BDX10(BL)-P1.25 1
# 5100036238 FLAT CABLE SML2CD-36X320-BDX8(BL)-P1.0-S 1
SCREWS
40011501 SCREW M3X8 PAN MACHINE W/SW BZC 2
40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 3
5100034002 SCREW M3X12 PAN MACHINE W/SMW+PW BZC 2
40454856 SCREW M4X10 BINDING MACHINE NI 1
5100023206 SCREW 2.6X8(JC7000220R0) BINDING TAPTITE P ZC 5
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 73
40011334 SCREW 3X12 BINDING TAPTITE-P FE BZC 14
40012490 SCREW 4X10 BINDING TAPTITE P BZC 21
5100011004 NUT HEX 529-08028-01-00 1
MISCELLANEOUS
# 5100035567 BENDER PB-H0302-RD 1
# 5100035160 PANEL SHEET L 1
# 5100035161 PANEL SHEET C 1
# 5100035182 PANEL SHEET R 1
# 5100035183 NAME SHEET 1
12359137 RUBBER FOOT SJ-5012 BLK 4
# 5100035188 LCD CUSHION CIRCLE 8
# 5100035186 LCD CUSHION LONG 2
# 5100035187 LCD CUSHION SHORT 2
00453223 LED SPACER LDS-70G 2
# 5100027106 CORD HOOK 40516-014 1
5100009656 DC PLUG SUPPORTER 1
5100017234 FERRITE CORE ZCAT2032-0930-BK 1
# 5100037900 FERRITE-CORE E04FG441312 1
12199584 GROUNDING TERMINAL M1698 4
13459202 TERMINAL(GROUND)L-TYPE M4 M1713 1
40120967 COATING CLIP CS-3 5
40016534 INSULOK TIE 204M/M T-18L 20
40122812 ACETATE TAPE NITTO #5 BLACK W15MM 30M -
40122556 DOUBLE FACED ADHESIVE TAPE #575X W30MM 30M 10P 30CM -
ACCESSORIES (Standard)
04236101 AC ADAPTOR WITHOUT AC CORD PSB-1U(S) UNIVERSAL 1
# 5100029121 AC CORD SET 100V 1.0M for 100V 1
5100012293 AC CORD SET 117VBL 1.0M FOR PSB for 117VBL 1
# 5100000692 AC CORD SET 117V U 1.0M for 117VU, 117VU/CS 1
5100018086 AC CORD SET 230VE 1.0M FOR EPS for 230VE 1
# 05017301 AC CORD SET 230V 1.0M FOR EU for 230VEU 1
5100029122 AC CORD SET 240V 1.0M FOR PSB for 240VA 1
# 5100036255 OWNER’S MANUAL MULTILANGUAGE 1
5100038316 SD CARD LSD4GB-000-625 (BLANK) 1
5100013329 SD CARD PROTECTOR 750-09064-01-00 1

Roland FA-06 Specifications

General

Control type	Buttons
Backlight color	Red
Backlight buttons	Yes
MIDI-keyboard number of keys	61 keys
Display type	LCD
Display diagonal	5 \
Product color	Black
Sound effects	Acoustic resonance, Synthesizer
Interface	USB
Headphone outputs	1
USB ports quantity	2
Compatible memory cards	SDHC
6.35 mm (1⁄4-inch) output	3
Power source type	AC
Bit rate	16 bit
Product type	Digital synthesizer
Keyboard number of keys	61
Maximum polyphony (notes)	128
Reverberation effects quantity	6

Weight and Dimensions

Depth	300 mm
Width	1008 mm
Height	101 mm
Weight	5700 g
