Roland FA-06 Service Notes

16
Feb. 2014 FA-06
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100035120 TOP CASE 1
# 5100035121 BOTTOM CASE 1
CHASSIS
03894945 REINFORCE BAR 750-04038-02-00 1
# 5100035136 LCD HOLDER 1
5100013330 SD CARD PROTECTOR HOLDER 750-09064-02-00 1
# 5100035184 SHIELD COVER 1
KNOB, BUTTON
# 5100035159 ZE R-KNOB LF BLK/RED 1
5100035158 ZS R-KNOB SF BLK/LCG 8
# 5100037825 G S-BUTTON BLK 1
5100035242 ZS S-KEYTOP LD1H BLK 12
# 5100035723 ZS S-KEYTOP LX1H BLK 2
5100035241 ZS S-KEYTOP SD1H BLK 23
5100035722 ZS S-KEYTOP SX1H BLK 12
# 5100035243 RUBBER SWITCH 1
SWITCH
04904123 PUSH SWITCH AC POWER SUPPLY 400-07040-01-00(PWL-2P2T-6SBP 1
02781634 TACT SWITCH SKRGAED010 49
00230489 SLIDE SWITCH SSSF12351A 1
JACK, EXT TERMINAL
04452945 3.5MM JACK YKB21-5344N 1
13449275 6.5MM JACK YKB21-5074 6
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 2
13449720 DC JACK HEC2305-016250 1
13429825 MIDI CONNECTOR YKF51-5054V 1
04459190 USB CONNECTOR A TYPE FEMALE YKF45-0033N 1
5100009531 USB CONNECTOR B TYPE FEMALE YKF45-0044N 1
DISPLAY UNIT
# 5100033810 LCD UMSH-8385MD-1T 1
KEYBOARD ASSY
04344189 KEYBOARD ASSY MSK-261 W/O CABLE (990-08040-10-07) 1
PWB ASSY
# 5100034949 MAIN BOARD ASSY 1
# 5100034953 JACK SHEET ASSY 1
* This unit includes the following parts.
******** JACK BOARD 1
******** MIDI BOARD 1
******** LCD BOARD 1
******** 7-SEG BOARD 1
******** PANEL-R BOARD 1
# 5100034964 PANEL SHEET ASSY 1
* This unit includes the following parts.
******** PANEL-L BOARD 1
******** PANEL-C BOARD 1
******** BENDER BOARD 1
******** ENCODER BOARD 1
DIODE
5100020884 LED A-303SR-A Q/W 1
# 5100010451 LED KPT-1608SURCK 20
# 5100036235 LED KPT-1608ZGC 17
5100008349 LED L-132XIT 34
# 5100036236 LED L-7104SRD-F 4

Roland FA-06 Specifications

General

Control type	Buttons
Backlight color	Red
Backlight buttons	Yes
MIDI-keyboard number of keys	61 keys
Display type	LCD
Display diagonal	5 \
Product color	Black
Sound effects	Acoustic resonance, Synthesizer
Interface	USB
Headphone outputs	1
USB ports quantity	2
Compatible memory cards	SDHC
6.35 mm (1⁄4-inch) output	3
Power source type	AC
Bit rate	16 bit
Product type	Digital synthesizer
Keyboard number of keys	61
Maximum polyphony (notes)	128
Reverberation effects quantity	6

Weight and Dimensions

Depth	300 mm
Width	1008 mm
Height	101 mm
Weight	5700 g
