7
Feb. 2014 FA-06
No. Part Code Part Name Description Q’ty
1 5100035158 ZS R-KNOB SF BLK/LCG 8
2 5100035159 ZE R-KNOB LF BLK/RED 1
3 ******** VR NUT attached to encoder 1
4 ******** VR WASHER attached to encoder 1
5 5100035183 NAME SHEET 1
6 5100035160 PANEL SHEET L 1
7 5100035161 PANEL SHEET C 1
8 5100035182 PANEL SHEET R 1
9 5100037825 G S-BUTTON BLK 1
10 5100009656 DC PLUG SUPPORTER 1
11 5100027106 CORD HOOK 40516-014 1
12 5100035120 TOP CASE 1
13 5100038316 SD CARD LSD4GB-000-625 (BLANK) 1
14 5100013329 SD CARD PROTECTOR 750-09064-01-00 1
15 5100013330 SD CARD PROTECTOR HOLDER 750-09064-02-00 1
16 40122812 ACETATE TAPE NITTO #5 BLACK W15MM 30M -
17 5100035187 LCD CUSHION SHORT 2
18 5100035186 LCD CUSHION LONG 2
19 5100033810 LCD UMSH-8385MD-1T 1
20 5100035188 LCD CUSHION CIRCLE 8
21 5100035136 LCD HOLDER 1
5100034953 JACK SHEET ASSY 1
* This unit includes the following parts.
22 ******** LCD BOARD 1
25 ******** 7SEG BOARD 1
31 ******** PANEL R BOARD 1
33 ******** JACK BOARD 1
34 ******** MIDI BOARD 1
23 5100017234 FERRITE CORE ZCAT2032-0930-BK 1
5100034964 PANEL SHEET ASSY 1
* This unit includes the following parts.
24 ******** ENCODER BOARD 1
27 ******** BENDER BOARD 1
29 ******** PANEL L BOARD 1
30 ******** PANEL C BOARD 1
26 5100035243 RUBBER SWITCH 1
28 5100035567 BENDER PB-H0302-RD 1
32 40122556 DOUBLE FACED ADHESIVE TAPE #575X W30MM 30M 10P 30CM -
35 5100034949 MAIN BOARD ASSY 1
36 5100035184 SHIELD COVER 1
37 5100037900 FERRITE-CORE E04FG441312 1
38 04344189 KEYBOARD ASSY MSK-261 W/O CABLE (990-08040-10-07) 1
39 03894945 REINFORCE BAR 750-04038-02-00 1
40 5100035121 BOTTOM CASE 1
41 12359137 RUBBER FOOT SJ-5012 BLK 4
To Next Page
