MIDI Implementation
40 2x 34 00 00 01 00-7F PAf LFO1 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 35 00 00 01 00-7F PAf LFO1 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 36 00 00 01 00-7F PAf LFO1 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 2x 37 00 00 01 00-7F PAf LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 38 00 00 01 00-7F PAf LFO2 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 39 00 00 01 00-7F PAf LFO2 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 3A 00 00 01 00-7F PAf LFO2 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 2x 40 00 00 01 28-58 CC1 PITCH CONTROL -24 - +24 [semitone] 40 0 [semitones]
40 2x 41 00 00 01 00-7F CC1 TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 42 00 00 01 00-7F CC1 AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 43 00 00 01 00-7F CC1 LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 44 00 00 01 00-7F CC1 LFO1 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 45 00 00 01 00-7F CC1 LFO1 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 46 00 00 01 00-7F CC1 LFO1 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 2x 47 00 00 01 00-7F CC1 LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 48 00 00 01 00-7F CC1 LFO2 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 49 00 00 01 00-7F CC1 LFO2 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 4A 00 00 01 00-7F CC1 LFO2 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 2x 50 00 00 01 28-58 CC2 PITCH CONTROL -24 - +24 [semitone] 40 0 [semitones]
40 2x 51 00 00 01 00-7F CC2 TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 52 00 00 01 00-7F CC2 AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 53 00 00 01 00-7F CC2 LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 54 00 00 01 00-7F CC2 LFO1 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 55 00 00 01 00-7F CC2 LFO1 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 56 00 00 01 00-7F CC2 LFO1 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 2x 57 00 00 01 00-7F CC2 LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 58 00 00 01 00-7F CC2 LFO2 PITCH DEPTH 0-600 [cent] 00 0 [cent]
40 2x 59 00 00 01 00-7F CC2 LFO2 TVF DEPTH 0-2400 [cent] 00 0 [cent]
40 2x 5A 00 00 01 00-7F CC2 LFO2 TVA DEPTH 0-100.0 [%] 00 0 [%]
40 4x 23 00 00 06 00-7F PART EFX TYPE (MSB, LSB) 00 00 - 7F 7F 00 00 0
* This EFX type is same to EFX type of System Parameter. When this EFX type is same to EFX type of System parameter, the part connect to EFX.
40 4x 25# 00-7F PART EFX MACRO 00-7F 00 00 0
40 4x 26# 00-7F PART EFX DEPTH 00-7F 00 00 0
40 4x 27# 00-7F PART EFX CONTROL1 00-7F 00 00 0
40 4x 28# 00-7F PART EFX CONTROL2 00-7F 00 00 0
40 4x 51 00 00 0B 00-7F HARMONIC BAR SET always 00 00 0
40 4x 52# 00-7F PERCUSSION 00(OFF) 00 OFF
01(4, Short)
02(2+2/3, Short)
41(4, Long)
42(2+2/3, Long)
40 4x 53# 00-7F HARMONIC BAR 16’ 00(OFF), 0F(ON) 00 OFF
40 4x 54# 00-7F HARMONIC BAR 5+1/3’ 00(OFF), 0F(ON) 00 OFF
40 4X 55# 00-7F HARMONIC BAR 8’ 00(OFF), 0F(ON) 00 OFF
40 4X 56# 00-7F HARMONIC BAR 4’ 00(OFF), 0F(ON) 00 OFF
40 4X 57# 00-7F HARMONIC BAR 2+2/3’ 00(OFF), 0F(ON) 00 OFF
40 4X 58# 00-7F HARMONIC BAR 2’ 00(OFF), 0F(ON) 00 OFF
40 4X 59# 00-7F HARMONIC BAR 1+3/5’ 00(OFF), 0F(ON) 00 OFF
40 4X 5A# 00-7F HARMONIC BAR 1+1/3’ 00(OFF), 0F(ON) 00 OFF
40 4X 5B# 00-7F HARMONIC BAR 1’ 00(OFF), 0F(ON) 00 OFF
●Drum Setup Parameters
* m: Map number (0 = MAP1, 1 = MAP2)
* rr: drum part note number (00H-7FH)
Address (H) Size (H) Data (H) ParameterDescription
41 m1 rr 00 00 01 00-7F PLAY NOTE NUMBER Pitch coarse
41 m2 rr 00 00 01 00-7F LEVEL TVA level
(= NRPN# 26)
41 m3 rr 00 00 01 00-7F ASSIGN GROUP NUMBER Non, 1-127
41 m4 rr 00 00 01 00-7F PANPOT -64 (RANDOM), -63 (LEFT) - +63 (RIGHT)
(= NRPN# 28, except RANDOM)
41 m5 rr 00 00 01 00-7F REVERB SEND LEVEL 0.0-1.0
(= NRPN# 29) Multiplicand of the part reverb depth
41 m6 rr 00 00 01 00-7F CHORUS SEND LEVEL 0.0-1.0
(= NRPN# 30) Multiplicand of the part chorus depth
41 m7 rr 00 00 01 00-01 Rx. NOTE OFF OFF/ON
41 m8 rr 00 00 01 00-01 Rx. NOTE ON OFF/ON
* When the Drum Set is changed, DRUM SETUP PARAMETER values will all be initialized.

Roland FP-4 Specifications

General

Polyphony	128 voices
Rated Power Output	12 W x 2
Effects	Reverb, Chorus
Recorder	Approx. 30, 000 notes
Display	3-digit 7-segment LED
Connectors	MIDI connectors (IN, OUT)
Power Supply	AC adaptor (included)
Included Accessories	AC Adaptor Power Cord Music Rest
Speakers	12 cm x 2
