24
MIDI Implementation
●0122: Rotary
The Rotary effect simulates the sound of the rotary speakers often used with the electric
organs of the past. Since the movement of the high range and low range rotors can be set
independently, the unique type of modulation characteristic of these speakers can be
simulated quite closely. This effect is most suitable for electric organ Patches.
●012d: Rotary2
This type provides modified response for the rotary speaker, with the low end boosted
further.
This effect is a descendant of the Roland VK Series’ built-in rotary speaker.
●0300: Rotary Multi
This is an effect combining the VK series internal effect with an organ effect with the same
features.
It comprises vibrato/chorus, overdrive, and rotary effects.
●015b: Stereo Delay1
This is a stereo delay.
No Parameter Value Description
1 Speed #1 0 - 1 Slow, Fast Simultaneously switch the rotational
speed of the low frequency rotor and
high frequency rotor.
Slow: Slows down the rotation to the
Slow Rate.
Fast: Speeds up the rotation to the
Fast Rate.
2 Woofer Slow
Speed
1 - 127 0.05-10.00 Hz Slow speed (Slow) of the low
frequency rotor
3 Woofer Fast
Speed
1 - 127 0.05-10.00 Hz Fast speed (Fast) of the low
frequency rotor
4 Woofer
Acceleration
0 - 15 0-15 Adjusts the time it takes the low
frequency rotor to reach the newly
selected speed when switching from
fast to slow (or slow to fast) speed.
Lower values will require longer
times.
5 Woofer Level 0 - 127 0-127 Volume of the low frequency rotor
6 Tweeter Slow
Speed
1 - 127 0.05-10.00 Hz Settings of the high frequency rotor
The parameters are the same as for
the low frequency rotor
7 Tweeter Fast
Speed
1 - 127 0.05-10.00 Hz
8 Tweeter
Acceleration
0 - 15 0-15
9 Tweeter Level 0 - 127 0-127
10 Separation #2 0 - 127 0-127 Spatial dispersion of the sound
11 Level 0 - 127 0-127 Output Level
No Parameter Value Description
1 Speed #1 0 - 1 Slow, Fast Rotational speed of the rotating
speaker
2 Brake #2 0 - 1 Off, On Switches the rotation of the rotary
speaker.
When this is turned on, the rotation
will gradually stop. When it is turned
off, the rotation will gradually
resume.
3 Woofer Slow
Speed
1 - 127 0.05-10.00 Hz Low-speed rotation speed of the
woofer
4 Woofer Fast
Speed
1 - 127 0.05-10.00 Hz High-speed rotation speed of the
woofer
5 Woofer Trans
Up
0 - 127 0-127 Adjusts the rate at which the woofer
rotation speeds up when the rotation
is switched from Slow to Fast.
6 Woofer Trans
Down
0 - 127 0-127 Adjusts the rate at which the woofer
rotation speeds up when the rotation
is switched from Fast to Slow.
7 Woofer Level 0 - 127 0-127 Volume of the woofer
8 Tweeter Slow
Speed
1 - 127 0.05-10.00 Hz Settings of the tweeter
The parameters are the same as for
the woofer.
9 Tweeter Fast
Speed
1 - 127 0.05-10.00 Hz
10 Tweeter Trans
Up
0 - 127 0-127
11 Tweeter Trans
Down
0 - 127 0-127
12 Tweeter Level 0 - 127 0-127
13 Spread 0 - 10 0-10 Sets the rotary speaker stereo image.
The higher the value set, the wider
the sound is spread out.
14 Low Gain 0 - 30 -15- +15 dB Gain of the low range
15 High Gain 0 - 30 -15- +15 dB Gain of the high range
16 Level 0 - 127 0-127 Output Level
No Parameter Value Description
1 Vib/Cho
Switch
0 - 1 Off, On Switches the vibrato and chorus
effects
2 Vib/Cho Type 0 - 5 V-1, V-2, V-3,
C-1, C-2, C-3
Vibrato and chorus effect types
V-1, V-2, V-3: Adds a wavering
(vibrato) that is created by changes in
the pitch.The effect deepens as the
value is increased
C-1, C-2, C-3: Adds a fullness and
breadth (chorus) to the sound.The
effect deepens as the value is
increased.
3 Vib/Cho
Vintage
0 - 2 ‘50, ‘60, ‘70 This reproduces the subtle
differences in the vibrato and chorus
effects in organs built in different
years.
4 Vib/Cho Level 0 - 127 0-127 Vibrato/chorus effect volume
5 OD Switch 0 - 1 Off, On Switches the overdrive effect
6 OD Drive #2 0 - 127 0-127 Amount of distortion
7 OD Level 0 - 127 0-127 Overdrive effect volume
8 Rotary Switch 0 - 1 Off, On Switches the rotary effect
9 Rotary Speed
#1
0 - 1 Slow, Fast Low- and high-frequency rotation
speeds (Rate)
Slow: (Slow Rate)
Fast: (Fast Rate)
10 R-Wf Slow Sp 1 - 127 0.05-10.00 Hz Rate with low-frequency rotor set to
Slow rate
11 R-Wf Fast Sp 1 - 127 0.05-10.00 Hz Rate with low-frequency rotor set to
Fast rate
12 R-Wf Accel 0 - 15 0-15 Speed at which the low-frequency
rotor’s rotation rate changes when
the rotation speed is switched
13 R-Wf Level 0 - 127 0-127 Low-frequency rotor volume
14 R-Tw Slow Sp 1 - 127 0.05-10.00 Hz High-frequency rotor settingThis
parameter is the same as that for the
low-frequency rotor.
15 R-Tw Fast Sp 1 - 127 0.05-10.00 Hz
16 R-Tw Accel 0 - 15 0-15
17 R-Tw Level 0 - 127 0-127
18 Rotary Separat 0 - 127 0-127 Amount of breadth in the sound
19 Rotary Level 0 - 127 0-127 Output volume
No Parameter Value Description
1 Delay Left
Mode
0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
2 Delay Left 0 - 127 1-1270 ms Adjusts the time until the delay
sound is heard. (Hz)
3 Delay Left 0 - 21 note Adjusts the time until the delay
sound is heard. (note)
4 Delay Right
Mode
0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
5 Delay Right 0 - 127 1-1270 ms Adjusts the time until the delay
sound is heard. (Hz)
6 Delay Right 0 - 21 note Adjusts the time until the delay
sound is heard. (note)
7 Phase Left 0 - 1 Normal,
Inverse
Phase of the delay sound
8 Phase Right 0 - 1
9 Feedback Mode 0 - 1 Normal, Cross Selects the way in which delay sound
is fed back into the effect. (See the
figures above.)
10 Feedback #1 49 - 89 0- +80 % Adjusts the amount of the delay
sound that’s fed back into the effect.
11 HF Damp 0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you don’t want to filter out any
high frequencies, set this parameter
to Bypass.
12 Low Gain 0 - 30 -15- +15 dB Gain of the low frequency range
13 High Gain 0 - 30 -15- +15 dB Gain of the high frequency range
14 Balance #2 0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
15 Level 0 - 127 0-127 Output level
To Next Page
