29
MIDI Implementation
●0208: Enhancer→Delay
This effect connects an enhancer and a delay in series.
●0209: Chorus→Delay
This effect connects a chorus and a delay in series.
●020a: Flanger→Delay
This effect connects a flanger and a delay in series.
●020b: Chorus→Flanger
This effect connects a chorus and a flanger in series.
No Parameter Value Description
1 Enhancer Sens
#1
0 - 127 0-127 Sensitivity of the enhancer
2 Enhancer Mix 0 - 127 0-127 Level of the overtones generated by
the enhancer
3 Delay Mode 0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
4 Delay Time 0 - 127 1-2540 ms Adjusts the delay time from the
direct sound until the delay sound is
heard. (Hz)
5 Delay Time 0 - 21 note Adjusts the delay time from the
direct sound until the delay sound is
heard. (note)
6 Delay
Feedback
49 - 89 0- +80 % Adjusts the proportion of the delay
sound that is fed back into the effect.
7 Delay HF
Damp
0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
Bypass.
8 Delay Balance
#2
0 - 100 D100:0W-
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
9 Level 0 - 127 0-127 Output Level
No Parameter Value Description
1 Chorus Pre
Delay
0 - 125 0.0-100.0 ms Adjusts the delay time from the
direct sound until the chorus sound
is heard.
2 Chorus Rate
Mode
0 - 1 Hz, note When this is set to “note,” the effect is
synchronized with the tempo.
3 Chorus Rate 1 - 127 0.05-10.00 Hz Frequency of modulation (Hz)
4 Chorus Rate 0 - 21 note Frequency of modulation (note)
5 Chorus Depth 0 - 127 0-127 Depth of modulation
6 Chorus Balance
#1
0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
7 Delay Mode 0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
8 Delay Time 0 - 127 1-2540 ms Adjusts the delay time from the
direct sound until the delay sound is
heard. (Hz)
9 Delay Time 0 - 21 note Adjusts the delay time from the
direct sound until the delay sound is
heard. (note)
10 Delay
Feedback
49 - 89 0- +80 % Adjusts the proportion of the delay
sound that is fed back into the effect.
11 Delay HF
Damp
0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
Bypass.
12 Delay Balance
#2
0 - 100 D100:0W-
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
13 Level 0 - 127 0-127 Output Level
No Parameter Value Description
1 Flanger Pre
Delay
0 - 125 0.0-100.0 ms Adjusts the delay time from when
the direct sound begins until the
flanger sound is heard.
2 Flanger Rate
Mode
0 - 1 Hz, note When this is set to “note,” the effect is
synchronized with the tempo.
3 Flanger Rate 1 - 127 0.05-10.00 Hz Frequency of modulation (Hz)
4 Flanger Rate 0 - 21 note Frequency of modulation (note)
5 Flanger Depth 0 - 127 0-127 Depth of modulation
6 Flanger
Feedback
0 - 98 -98- +98 % Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
7 Flanger Balance
#1
0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the flanger sound (W)
8 Delay Mode 0 - 1 ms, note When this is set to “note,” the effect is
synchronized with the tempo.
9 Delay Time 0 - 127 1-2540 ms Adjusts the delay time from the
direct sound until the delay sound is
heard. (Hz)
10 Delay Time 0 - 21 note Adjusts the delay time from the
direct sound until the delay sound is
heard. (note)
11 Delay
Feedback
49 - 89 0- +80 % Adjusts the proportion of the delay
sound that is fed back into the effect.
12 Delay HF
Damp
0 - 17 200-8000 Hz,
Bypass
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
Bypass.
13 Delay Balance
#2
0 - 100 D100:0W-
D0:100W
Adjusts the volume balance between
the sound that is sent through the
delay (W) and the sound that is not
sent through the delay (D).
14 Level 0 - 127 0-127 Output Level
No Parameter Value Description
1 Chorus Pre
Delay
0 - 125 0.0-100.0 ms Adjusts the delay time from the
direct sound until the chorus sound
is heard.
2 Chorus Rate
Mode
0 - 1 Hz, note When this is set to “note,” the effect is
synchronized with the tempo.
3 Chorus Rate 1 - 127 0.05-10.00 Hz Modulation frequency of the chorus
effect (Hz)
4 Chorus Rate 0 - 21 note Modulation frequency of the chorus
effect (note)
5 Chorus Depth 0 - 127 0-127 Modulation depth of the chorus
effect
6 Chorus Balance
#1
0 - 100 D100:0W-
D0:100W
Volume balance between the direct
sound (D) and the chorus sound (W)
7 Flanger Pre
Delay
0 - 125 0.0-100.0 ms Adjusts the delay time from when
the direct sound begins until the
flanger sound is heard.
8 Flanger Rate
Mode
0 - 1 Hz, note When this is set to “note,” the effect is
synchronized with the tempo.
9 Flanger Rate 1 - 127 0.05-10.00 Hz Modulation frequency of the flanger
effect (Hz)
10 Flanger Rate 0 - 21 note Modulation frequency of the flanger
effect (note)
11 Flanger Depth 0 - 127 0-127 Modulation depth of the flanger
effect
12 Flanger
Feedback
0 - 98 -98- +98 % Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
13 Flanger Balance
#2
0 - 100 D100:0W-
D0:100W
Adjusts the volume balance between
the sound that is sent through the
flanger (W) and the sound that is not
sent through the flanger (D).
14 Level 0 - 127 0-127 Output Level
