15
●Drum Setup Parameters
* m: Map number (0 = MAP1, 1 = MAP2)
* rr: drum part note number (00H-7FH)
Address (H)
Size (H) Data (H) Parameter Description
41 m1 rr 00 00 01 00-7F PLAY NOTE NUMBER Pitch coarse
41 m2 rr 00 00 01 00-7F LEVEL TVA level
(= NRPN# 26)
41 m3 rr 00 00 01 00-7F ASSIGN GROUP NUMBER Non, 1-127
41 m4 rr 00 00 01 00-7F PANPOT -64 (RANDOM), -63 (LEFT) - +63 (RIGHT)
(= NRPN# 28, except RANDOM)
41 m5 rr 00 00 01 00-7F REVERB SEND LEVEL 0.0-1.0
(= NRPN# 29) Multiplicand of the part reverb depth
41 m6 rr 00 00 01 00-7F CHORUS SEND LEVEL 0.0-1.0
(= NRPN# 30) Multiplicand of the part chorus depth
41 m7 rr 00 00 01 00-01 Rx. NOTE OFF OFF/ON
41 m8 rr 00 00 01 00-01 Rx. NOTE ON OFF/ON
* When the Drum Set is changed, DRUM SETUP PARAMETER values will all be initialized.
