Roland JUNO-D Midi Implementation

10
* Chord
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Chord Pattern |
| 00 01 00 | Chord Pattern |
| : | |
| 00 0B 00 | Chord Pattern |
| 00 10 00 | (reserved) |
+——————————————————————————————————————————————————————————————————————————————+
* Setup
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0000 0aaa | Mode Select (0 — 4) |
| | | PERFORMANCE, PATCH, GM1, GM2, GS |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 01 | 0aaa aaaa | Performance Bank Select MSB (CC# 0) (0 — 127) |
| 00 02 | 0aaa aaaa | Performance Bank Select LSB (CC# 32) (0 — 127) |
| 00 03 | 0aaa aaaa | Performance Program Number (PC) (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 04 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 — 127) |
| 00 05 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 — 127) |
| 00 06 | 0aaa aaaa | Patch Program Number (PC) (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 07 | 0000 000a | MFX Switch (0 — 1) |
| | | BYPASS, ON |
| 00 08 | 0000 000a | Chorus Switch (0 — 1) |
| | | OFF, ON |
| 00 09 | 0000 000a | Reverb Switch (0 — 1) |
| | | OFF, ON |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0A | 0000 000a | Arpeggio Switch (0 — 1) |
| | | OFF, ON |
| 00 0B | 0000 000a | Arpeggio Group (0 — 1) |
| | | USER, PRESET |
| 00 0C | 0000 aaaa | Arpeggio Number (0 — 8) |
| | | 1 — 9 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 0000 000a | Chord Switch (0 — 1) |
| | | OFF, ON |
| 00 0E | 0000 000a | Chord Group (0 — 1) |
| | | USER, PRESET |
| 00 0F | 0000 aaaa | Chord Number (0 — 15) |
| | | 1 — 16 |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 10 | 000a aaaa | D Beam Assign (0 — 26) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, BEND UP, BEND DOWN, |
| | | SEQ START/STOP, SOLO SYNTH, ACTIVE EXP |
| 00 11 | 0000 aaaa | D Beam Sens (1 — 10) |
| 00 12 | 0000 000a | D Beam Polarity (0 — 1) |
| | | NORMAL, REVERSE |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 13 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* System Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
|# 00 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Master Tune (24 — 2024) |
| | | —100.0 — 100.0 [cent] |
| 00 04 | 00aa aaaa | Master Key Shift (40 — 88) |
| | | —24 — +24 |
| 00 05 | 0aaa aaaa | Master Level (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 06 | 0000 000a | Hold Pedal Polarity (0 — 1) |
| | | STANDARD, REVERSE |
| 00 07 | 000a aaaa | Control Pedal Assign (0 — 23) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PUNCH IN/OUT, TAP TEMPO |
| 00 08 | 000a aaaa | Modulation Assign (0 — 21) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH |
| 00 09 | 000a aaaa | C1 Knob Assign (0 — 22) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PATCH MODIFY |
| 00 0A | 000a aaaa | C2 Knob Assign (0 — 22) |
| | | MODULATION, PORTA TIME, VOLUME, |
| | | BALANCE, PAN, EXPRESSION, |
| | | PORTAMENTO, SOSTENUTO, SOFT, |
| | | RESONANCE, RELEASE TIME, ATTACK TIME, |
| | | CUTOFF, DECAY TIME, LFO RATE, |
| | | LFO DEPTH, LFO DELAY, CHO SEND LEVEL, |
| | | REV SEND LEVEL, MFX PARAMETER1, MFX PARAMETER2, |
| | | AFTERTOUCH, PATCH MODIFY |

Roland JUNO-D Specifications

General

Type	Digital Synthesizer
Polyphony	64 voices
Preset Performances	32
Arpeggiator	Yes
Rhythm Guide	Yes
MIDI	Yes
Effects	Reverb, Chorus
Keyboard	61 keys (velocity-sensitive)
Controllers	Pitch Bend/Modulation Lever
Connectors	Output (L/Mono, R), Headphones, MIDI (In, Out)
Power Supply	DC 9V
Waveforms	PCM
USB	Yes
User Patches	128 patches
Oscillators	Not specified in detail, uses PCM waveforms
