Page #9 background imageLoading...
Page #9 background image
9
3. Parameter Address Map
* Transmission of “#” marked address is divided to some packets. For example, ABH in hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this order.
JUNO-D (MODEL ID = 00H 64H)
+——————————————————————————————————————————————————————————————————————————————+
| Start | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 00 | Setup |
|—————————————+————————————————————————————————————————————————————————————————|
| 01 00 00 00 | System |
|—————————————+————————————————————————————————————————————————————————————————|
| 10 00 00 00 | Temporary Performance |
| 11 00 00 00 | Temporary Patch/Rhythm (Performance Mode Part 1) |
| 11 02 00 00 | Temporary Patch/Rhythm (Performance Mode Part 2) |
| : | |
| 11 1E 00 00 | Temporary Patch/Rhythm (Performance Mode Part 16) |
| 18 00 00 00 | Temporary Patch/Rhythm (Patch Mode) |
| 1A 00 00 00 | Temporary Arpeggio |
| 1C 00 00 00 | Temporary Chord |
|—————————————+————————————————————————————————————————————————————————————————|
| 20 00 00 00 | User Performance (001) |
| 20 01 00 00 | User Performance (002) |
| : | |
| 20 07 00 00 | User Performance (008) |
|—————————————+————————————————————————————————————————————————————————————————|
| 30 00 00 00 | User Patch (001) |
| 30 01 00 00 | User Patch (002) |
| : | |
| 30 7F 00 00 | User Patch (128) |
|—————————————+————————————————————————————————————————————————————————————————|
| 40 00 00 00 | User Rhythm (01) |
| 40 01 00 00 | User Rhythm (02) |
|—————————————+————————————————————————————————————————————————————————————————|
| 50 00 00 00 | User Arpeggio (1) |
| 50 01 00 00 | User Arpeggio (2) |
| : | |
| 50 07 00 00 | User Arpeggio (8) |
|—————————————+————————————————————————————————————————————————————————————————|
| 60 00 00 00 | User Chord (1) |
| 60 01 00 00 | User Chord (2) |
| : | |
| 60 07 00 00 | User Chord (8) |
+——————————————————————————————————————————————————————————————————————————————+
* Temporary Patch/Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Temporary Patch |
| 01 00 00 | Temporary Rhythm |
+——————————————————————————————————————————————————————————————————————————————+
* Performance
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Performance Common |
| 00 02 00 | Performance MFX |
| 00 04 00 | Performance Chorus |
| 00 06 00 | Performance Reverb |
| 00 10 00 | Performance Part (Part 1) |
| 00 11 00 | Performance Part (Part 2) |
| : | |
| 00 1F 00 | Performance Part (Part 16) |
+——————————————————————————————————————————————————————————————————————————————+
* Patch
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Patch Common |
| 00 02 00 | Patch MFX |
| 00 04 00 | Patch Chorus |
| 00 06 00 | Patch Reverb |
| 00 10 00 | Patch Tone (1) |
| 00 11 00 | Patch Tone (2) |
+——————————————————————————————————————————————————————————————————————————————+
* Rhythm
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Rhythm Common |
| 00 02 00 | Rhythm MFX |
| 00 04 00 | Rhythm Chorus |
| 00 06 00 | Rhythm Reverb |
| 00 10 00 | Rhythm Tone (Key # 21) |
| 00 11 00 | Rhythm Tone (Key # 22) |
| : | |
| 00 67 00 | Rhythm Tone (Key # 108) |
+——————————————————————————————————————————————————————————————————————————————+
* Arpeggio
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 | Arpeggio Setup |
| 00 10 00 | (reserved) |
+——————————————————————————————————————————————————————————————————————————————+
