Roland JUNO-D Midi Implementation

14
* Patch Common
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 0aaa aaaa | Patch Name 1 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 01 | 0aaa aaaa | Patch Name 2 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 02 | 0aaa aaaa | Patch Name 3 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 03 | 0aaa aaaa | Patch Name 4 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 04 | 0aaa aaaa | Patch Name 5 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 05 | 0aaa aaaa | Patch Name 6 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 06 | 0aaa aaaa | Patch Name 7 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 07 | 0aaa aaaa | Patch Name 8 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 08 | 0aaa aaaa | Patch Name 9 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 09 | 0aaa aaaa | Patch Name 10 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0A | 0aaa aaaa | Patch Name 11 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0B | 0aaa aaaa | Patch Name 12 (32 — 127) |
| | | 32 — 127 [ASCII] |
| 00 0C | 0aaa aaaa | Patch Category (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 0D | 0000 00aa | Keyboard Mode (0 — 2) |
| | | SINGLE, SPLIT, DUAL |
| 00 0E | 0aaa aaaa | Patch Level (0 — 127) |
| 00 0F | 0aaa aaaa | Tone Balance (CC# 8) (0 — 127) |
| | | —64(LOWER) — +63(UPPER) |
| 00 10 | 0aaa aaaa | Split Point (21 — 108) |
| | | A0 — C8 |
| 00 11 | 0000 00aa | Split Arpeggio (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 12 | 0000 00aa | Solo Switch (MONO ON/POLY ON) (0 — 3) |
| | | OFF, ON, UPPER, LOWER |
| 00 13 | 0000 00aa | Modulation Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 14 | 0000 00aa | Pitch Bend Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 15 | 0000 00aa | Modify Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 16 | 0000 00aa | Expression Destination (0 — 2) |
| | | UPPER, LOWER, BOTH |
| 00 17 | 0000 000a | Active Expression Switch (0 — 1) |
| | | OFF, ON |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 00 18 | Total Size |
+——————————————————————————————————————————————————————————————————————————————+
* Patch MFX
+——————————————————————————————————————————————————————————————————————————————+
| Offset | |
| Address | Description |
|—————————————+————————————————————————————————————————————————————————————————|
| 00 00 | 00aa aaaa | MFX Type (0 — 47) |
| | | 00 THROUGH, 01 STEREO EQ, 02 OVERDRIVE, |
| | | 03 DISTORTION, 04 PHASER, 05 SPECTRUM, |
| | | 06 ENHANCER, 07 AUTO WAH, 08 ROTARY, |
| | | 09 COMPRESSOR, 10 LIMITER, 11 HEXA—CHORUS, |
| | | 12 TREMOLO CHO, 13 SPACE—D, 14 St CHORUS, |
| | | 15 St FLANGER, 16 STEP FLANGER, 17 St DELAY, |
| | | 18 LONG DELAY, 19 MOD DELAY, 20 3 TAP DELAY, |
| | | 21 4 TAP DELAY, 22 TM CTRL DLY, 23 2V PCH SHIFT, |
| | | 24 FB PCH SHIFT, 25 REVERB, 26 GATED REVERB, |
| | | 27 OD>CHORUS, 28 OD>FLANGER, 29 OD>DELAY, |
| | | 30 DIST>CHORUS, 31 DIST>FLANGER, 32 DIST>DELAY, |
| | | 33 ENH>CHORUS, 34 ENH>FLANGER, 35 ENH>DELAY, |
| | | 36 CHORUS>DELAY, 37 FLG>DELAY, 38 CHO>FLANGER, |
| | | 39 CHORUS/DELAY, 40 FLG/DELAY, 41 CHO/FLANGER, |
| | | 42 LOFI, 43 SLICER, 44 TREMOLO, |
| | | 45 AUTO PAN, 46 TUMBLING DELAY, |
| | | 47 FEEDBACK RIPPER |
| 00 01 | 0aaa aaaa | MFX Send Level to Chorus (0 — 127) |
| 00 02 | 0aaa aaaa | MFX Send Level to Reverb (0 — 127) |
|—————————————+———————————+————————————————————————————————————————————————————|
| 00 03 | 0000 aaaa | MFX Control Assign 1 (0 — 2) |
| | | OFF, 1 — 2 |
| 00 04 | 0000 aaaa | MFX Control Assign 2 (0 — 2) |
| | | OFF, 1 — 2 |
|# 00 05 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 1 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 2 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 0D | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 3 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 4 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 15 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | MFX Parameter 5 (12768 — 52768) |
| | | —20000 — +20000 |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |

Roland JUNO-D Specifications

General

Type	Digital Synthesizer
Polyphony	64 voices
Preset Performances	32
Arpeggiator	Yes
Rhythm Guide	Yes
MIDI	Yes
Effects	Reverb, Chorus
Keyboard	61 keys (velocity-sensitive)
Controllers	Pitch Bend/Modulation Lever
Connectors	Output (L/Mono, R), Headphones, MIDI (In, Out)
Power Supply	DC 9V
Waveforms	PCM
USB	Yes
User Patches	128 patches
Oscillators	Not specified in detail, uses PCM waveforms
