TD-15 Multi-eect List
The TD-15 provides ten types of multi-eect (MULTI-FX).
No. Eect Name
00 THRU
01 COMPRESSOR
02 SATURATOR
03 ISOLATOR
04 FILTER
05 AUTO WAH
06 OVERDRIVE
07 DISTORTION
08 LO-FI
09 PHASER
10 RING MOD
00: THRU
The eect won’t be applied.
01: COMPRESSOR
Flattens out high levels and boosts low levels, smoothing
out uctuations in volume.
Parameter Value Explanation
Threshold -48–0 dB
Adjusts the volume at which
compression begins
Make Up 0–24 dB Adjusts the output gain
Ratio
2:1, 3:1, 4:1, 8:1,
100:1
Compression ratio
Attack 0–100
Sets the time from when the
input exceeds the Threshold
until the volume starts being
compressed
Release 0–99
Adjusts the time after the
signal volume falls below
the Threshold Level until
compression is no longer
applied
Low Gain -15–+15 dB
Gain of the low frequency
range
High Gain -15–+15 dB
Gain of the high frequency
range
02: SATURATOR
A saturator which distorts the sound is connected in
parallel with a compressor, producing a rougher tonal
character and boosting the loudness. This also cuts the
low-frequency region of the input audio.
Parameter Value Explanation
Sat Drive 0–127
Amount of distortion of the
saturator
Sat Level 0–127
Output volume of the
saturator
Comp Level 0–127
Output volume of the
compressor
High Gain -12–+6 dB
Amount of high-range boost/
cut
Sat&Comp
Mix
0–127
Volume at which the satura-
tor sound and compressor
sound are mixed with the
original sound
Level 0–127 Output level
