15
Appendix
Main Specications
9 VIDEO Section
Input Connector HDMI IN
HDMI type A
* HDCP not Supported
* Multi-format Supported
Input Formats
480/59.94p, 576/50p, 720/59.94p, 720/50p,
1080/29.97p, 1080/25p, 1080/59.94p, 1080/50p,
SVGA (800 x 600) 60 Hz / 75 Hz, XGA (1024 x 768) 60 Hz / 75 Hz,
WXGA (1280 x 800) 60 Hz / 75 Hz, HD (1280 x 720) 60 Hz / 75 Hz,
SXGA (1280 x 1024) 60 Hz / 75 Hz, FWXGA (1366 x 768) 60 Hz / 75 Hz,
SXGA+ (1400 x 1050) 60 Hz / 75 Hz, UXGA (1600 x 1200) 60 Hz,
FHD (1920 x 1080) 60 Hz
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E, VESA DMT Version 1.0 Revision 11.
Output Connectors USB STREAM USB 3.0 B
USB Video Output
Format
YUY2 (Uncompressed), Motion JPEG (Compressed)
USB Video Output
Resolution
1920 x 1080, 1280 x 720, 640 x 480
* Maximum frame rate is 60 fps.
9AUDIO Section
Audio Processing Sample Rate 48 kHz, 24 bits
Analog Connectors
MIC XLR type (Balanced, Phantom power DC 48 V, 14 mA Max)
HEADSET Stereo miniature phone type (CTIA, PLUG-IN power)
AUX IN Stereo miniature phone type
MONITOR OUT Stereo miniature phone type
Digital Connectors
HDMI IN HDMI Type A
USB STREAM USB 3.0 B
Nominal Input Level
MIC IN -54 to -14 dBu (Maximum input level: +4 dBu)
HEADSET -20 dBu (Maximum input level: -2 dBu)
AUX IN -10 dBu (Maximum input level: +8 dBu)
Nominal Output
Level
MONITOR OUT -10 dBu
HEADSET 9 mW + 9 mW (32
Ω load)
Input Impedance
MIC IN 5.8 k
Ω
AUX IN 10 kΩ
HEADSET 1 kΩ
Output Impedance
MONITOR OUT 1 k
Ω
HEADSET 22 Ω
Digital Audio
Format
HDMI IN Linear PCM, 48 kHz/44.1 kHz, 24/20/16 bits, Stereo
USB STREAM Linear PCM, 48 kHz, 16 bits, Stereo
Audio Eects Anti-Feedback, Echo Canceller, Ducker, Voice Change, Reverb, Noise Suppressor, Equalizer, Expander, Compressor, Delay
Audio File Player
Number of Tracks 2
Data Formats WAV (Linear PCM, 48 kHz, 16 bits, stereo/mono)
Maximum Time 5 seconds/track
9Common Section
Other functions
MIC Mute (TALK button)
Audio Mute (AUDIO OUT button)
Video O (VIDEO OUT button)
Slideshow Control
Power Supply Supplied from the computer via USB
Current Draw 900 mA (4.5 W)
Operation
Temperature
+0 to +40 degrees Celsius
+32 to +104 degrees Fahrenheit
Dimensions
124 (W) x 117 (D) x 52 (H) mm
4-15/16 (W) x 4-5/8 (D) x 2-1/16 (H) inches
Weight (excluding
cables)
460 g
1 lb 0.3 oz
Accessories Leaet “Read Me First,” USB 3.0 cable
* 0 dBu = 0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the Roland website.
