Roland V-Synth GT Supplementary Guide

10
MIDI Implementation
| 00 66 | 0aaa aaaa | Matrix Control 6 Dest 2 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3, |
| | | TVA-PAN |
| 00 67 | 0aaa aaaa | Matrix Control 6 Sens 2 (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 68 | 0aaa aaaa | Matrix Control 7 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | +PAD-X, +PAD-Y, PAD-X, PAD-Y, TRIP-R, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, VELO, KEYF |
| 00 69 | 0aaa aaaa | Matrix Control 7 Dest 1 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3, |
| | | TVA-PAN |
| 00 6A | 0aaa aaaa | Matrix Control 7 Sens 1 (1 - 127) |
| | | -63 - +63 |
| 00 6B | 0aaa aaaa | Matrix Control 7 Dest 2 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3, |
| | | TVA-PAN |
| 00 6C | 0aaa aaaa | Matrix Control 7 Sens 2 (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 6D | 0aaa aaaa | Matrix Control 8 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | +PAD-X, +PAD-Y, PAD-X, PAD-Y, TRIP-R, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, VELO, KEYF |
| 00 6E | 0aaa aaaa | Matrix Control 8 Dest 1 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3, |
| | | TVA-PAN |
| 00 6F | 0aaa aaaa | Matrix Control 8 Sens 1 (1 - 127) |
| | | -63 - +63 |
| 00 70 | 0aaa aaaa | Matrix Control 8 Dest 2 (0 - 78) |
| | | OFF, |
| | | OSC1-PITCH, OSC1-TIME/PW, OSC1-FORMA/FAT, |
| | | OSC1-LVL, |
| | | OSC1-PENV-ATK, OSC1-PENV-DCY, OSC1-PENV-REL, |
| | | OSC1-TENV-ATK, OSC1-TENV-DCY, OSC1-TENV-REL, |
| | | OSC1-FENV-ATK, OSC1-FENV-DCY, OSC1-FENV-REL, |
| | | OSC1-AENV-ATK, OSC1-AENV-DCY, OSC1-AENV-REL, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC2-PITCH, OSC2-TIME/PW, OSC2-FORMA/FAT, |
| | | OSC2-LVL, |
| | | OSC2-PENV-ATK, OSC2-PENV-DCY, OSC2-PENV-REL, |
| | | OSC2-TENV-ATK, OSC2-TENV-DCY, OSC2-TENV-REL, |
| | | OSC2-FENV-ATK, OSC2-FENV-DCY, OSC2-FENV-REL, |
| | | OSC2-AENV-ATK, OSC2-AENV-DCY, OSC2-AENV-REL, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3, |
| | | TVA-PAN |
| 00 71 | 0aaa aaaa | Matrix Control 8 Sens 2 (1 - 127) |
| | | -63 - +63 |
|-------------+----------------------------------------------------------------|
| 00 00 00 72 | Total Size |
+------------------------------------------------------------------------------+
❍ Tone Common 2
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | AP-Synthesis Switch (0 - 1) |
| | | OFF, ON |
| 00 01 | 0000 000a | Vocal Designer Structure Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 02 | 0000 000a | Vocal Designer Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 03 | 00aa aaaa | (reserved) (0 - 63) |
| 00 04 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 05 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 06 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 07 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 08 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 09 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0A | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0B | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0C | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0D | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0E | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0F | 0aaa aaaa | (reserved) (0 - 127) |
| 00 10 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 11 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 12 | 0aaa aaaa | (reserved) (0 - 127) |
|-------------+----------------------------------------------------------------|
| 00 00 00 13 | Total Size |
+------------------------------------------------------------------------------+
❍ Tone T-FX
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | T-FX Type (0 - 41) |
| | | |
| 00 01 | 0aaa aaaa | T-FX Master Level (0 - 127) |
| 00 02 | 0aaa aaaa | T-FX Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | T-FX Reverb Send Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 04 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 08 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 10 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 14 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 18 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 20 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 24 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 28 | 0000 aaaa | |
