Roland V-Synth GT Supplementary Guide

11
MIDI Implementation
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 30 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 34 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 38 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 40 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 44 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 48 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 50 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 54 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 21 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 58 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 22 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 23 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 60 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 24 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 64 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 25 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 68 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 26 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 6C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 27 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 70 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 28 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 74 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 29 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 78 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 30 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 7C | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 31 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 00 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | T-FX Parameter 32 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 01 04 | Total Size |
+------------------------------------------------------------------------------+
❍ Tone Step Modulator
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | Master Switch (0 - 1) |
| | | OFF, ON |
| 00 01 | 0000 00aa | Key Sync (0 - 2) |
| | | OFF, PART, VOICE |
|-------------+-----------+----------------------------------------------------|
| 00 02 | 0000 000a | Track 1 Switch (0 - 1) |
| | | OFF, ON |
| 00 03 | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 04 | 0000 000a | Track 1 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 05 | 0000 0aaa | Track 1 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 06 | 0000 aaaa | Track 1 End Point (0 - 15) |
| | | 1 - 16 |
| 00 07 | 0000 0aaa | Track 1 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 08 | 0000 aaaa | Track 1 Zone (0 - 15) |
| | | 1 - 16 |
| 00 09 | 0aaa aaaa | Track 1 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3 |
| 00 0A | 0aaa aaaa | Track 1 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 0B | 0aaa aaaa | Track 1 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 0C | 0aaa aaaa | Track 1 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 0D | 0aaa aaaa | Track 1 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 0E | 0aaa aaaa | Track 1 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 0F | 0aaa aaaa | Track 1 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 10 | 0aaa aaaa | Track 1 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 11 | 0aaa aaaa | Track 1 Step 08 Value (1 - 127) |
| | | -63 - +63 |
| 00 12 | 0aaa aaaa | Track 1 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 13 | 0aaa aaaa | Track 1 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 14 | 0aaa aaaa | Track 1 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 15 | 0aaa aaaa | Track 1 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 16 | 0aaa aaaa | Track 1 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 17 | 0aaa aaaa | Track 1 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 18 | 0aaa aaaa | Track 1 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 19 | 0aaa aaaa | Track 1 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 1A | 0000 000a | Track 2 Switch (0 - 1) |
| | | OFF, ON |
| 00 1B | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 1C | 0000 000a | Track 2 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 1D | 0000 0aaa | Track 2 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 1E | 0000 aaaa | Track 2 End Point (0 - 15) |
| | | 1 - 16 |
| 00 1F | 0000 0aaa | Track 2 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 20 | 0000 aaaa | Track 2 Zone (0 - 15) |
| | | 1 - 16 |
| 00 21 | 0aaa aaaa | Track 2 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3 |
| 00 22 | 0aaa aaaa | Track 2 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 23 | 0aaa aaaa | Track 2 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 24 | 0aaa aaaa | Track 2 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 25 | 0aaa aaaa | Track 2 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 26 | 0aaa aaaa | Track 2 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 27 | 0aaa aaaa | Track 2 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 28 | 0aaa aaaa | Track 2 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 29 | 0aaa aaaa | Track 2 Step 08 Value (1 - 127) |
| | | -63 - +63 |
