Roland V-Synth GT Supplementary Guide

12
MIDI Implementation
| 00 2A | 0aaa aaaa | Track 2 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 2B | 0aaa aaaa | Track 2 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 2C | 0aaa aaaa | Track 2 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 2D | 0aaa aaaa | Track 2 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 2E | 0aaa aaaa | Track 2 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 2F | 0aaa aaaa | Track 2 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 30 | 0aaa aaaa | Track 2 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 31 | 0aaa aaaa | Track 2 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 32 | 0000 000a | Track 3 Switch (0 - 1) |
| | | OFF, ON |
| 00 33 | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 34 | 0000 000a | Track 3 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 35 | 0000 0aaa | Track 3 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 36 | 0000 aaaa | Track 3 End Point (0 - 15) |
| | | 1 - 16 |
| 00 37 | 0000 0aaa | Track 3 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 38 | 0000 aaaa | Track 3 Zone (0 - 15) |
| | | 1 - 16 |
| 00 39 | 0aaa aaaa | Track 3 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3 |
| 00 3A | 0aaa aaaa | Track 3 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 3B | 0aaa aaaa | Track 3 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 3C | 0aaa aaaa | Track 3 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 3D | 0aaa aaaa | Track 3 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 3E | 0aaa aaaa | Track 3 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 3F | 0aaa aaaa | Track 3 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 40 | 0aaa aaaa | Track 3 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 41 | 0aaa aaaa | Track 3 Step 08 Value (1 - 127) |
| | | -63 - +63 |
| 00 42 | 0aaa aaaa | Track 3 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 43 | 0aaa aaaa | Track 3 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 44 | 0aaa aaaa | Track 3 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 45 | 0aaa aaaa | Track 3 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 46 | 0aaa aaaa | Track 3 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 47 | 0aaa aaaa | Track 3 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 48 | 0aaa aaaa | Track 3 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 49 | 0aaa aaaa | Track 3 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+-----------+----------------------------------------------------|
| 00 4A | 0000 000a | Track 4 Switch (0 - 1) |
| | | OFF, ON |
| 00 4B | 0000 000a | Track Loop Switch (0 - 1) |
| | | OFF, ON |
| 00 4C | 0000 000a | Track 4 Type (0 - 1) |
| | | STEP, SMOOTH |
| 00 4D | 0000 0aaa | Track 4 Grid (0 - 5) |
| | | QUARTER, 8TH, 8TH-T, 16TH, |
| | | 16TH-T, 32TH |
| 00 4E | 0000 aaaa | Track 4 End Point (0 - 15) |
| | | 1 - 16 |
| 00 4F | 0000 0aaa | Track 4 Direction (0 - 5) |
| | | FWD1, FWD2, FWD3, BWD1, BWD2, BWD3 |
| 00 50 | 0000 aaaa | Track 4 Zone (0 - 15) |
| | | 1 - 16 |
| 00 51 | 0aaa aaaa | Track 4 Destination (0 - 71) |
| | | OSC1+2-PIT-CRS, OSC1+2-PIT-FINE, PORTA-TIME, |
| | | OSC1-PIT-CRS, OSC1-PIT-FINE, |
| | | OSC1-PITCH, OSC1-PENV-DPT, |
| | | OSC1-TIME/PW, OSC1-TENV-DPT, |
| | | OSC1-FORMA/FAT, OSC1-FENV-DPT, |
| | | OSC1-LFO-RATE, OSC1-LFO-PCH, OSC1-LFO-TM/PW, |
| | | OSC1-LFO-FR/FT, OSC1-LFO-LVL, |
| | | OSC1-LVL, |
| | | OSC2-PIT-CRS, OSC2-PIT-FINE, |
| | | OSC2-PITCH, OSC2-PENV-DPT, |
| | | OSC2-TIME/PW, OSC2-TENV-DPT, |
| | | OSC2-FORMA/FAT, OSC2-FENV-DPT, |
| | | OSC2-LFO-RATE, OSC2-LFO-PCH, OSC2-LFO-TM/PW, |
| | | OSC2-LFO-FR/FT, OSC2-LFO-LVL, |
| | | OSC2-LVL, |
| | | CSM1-PRM1, CSM1-PRM2, |
| | | CSM1-ENV1-ATK, CSM1-ENV1-DCY, |
| | | CSM1-ENV1-SUS, CSM1-ENV1-REL, |
| | | CSM1-ENV2-ATK, CSM1-ENV2-DCY, |
| | | CSM1-ENV2-SUS, CSM1-ENV2-REL, |
| | | CSM1-LFO-RATE, CSM1-LFO-PRM1, CSM1-LFO-PRM2, |
| | | CSM2-PRM1, CSM2-PRM2, |
| | | CSM2-ENV1-ATK, CSM2-ENV1-DCY, |
| | | CSM2-ENV1-SUS, CSM2-ENV1-REL, |
| | | CSM2-ENV2-ATK, CSM2-ENV2-DCY, |
| | | CSM2-ENV2-SUS, CSM2-ENV2-REL, |
| | | CSM2-LFO-RATE, CSM2-LFO-PRM1, CSM2-LFO-PRM2, |
| | | TVA-LVL, TVA-PAN, |
| | | TVA-ENV-ATK, TVA-ENV-DCY, |
| | | TVA-ENV-SUS, TVA-ENV-REL, |
| | | TVA-LFO-RATE, TVA-LFO-LVL, TVA-LFO-PAN, |
| | | T-FX-SEND, CHO-SEND, REV-SEND, |
| | | T-FX-PRM1, T-FX-PRM2, T-FX-PRM3 |
| 00 52 | 0aaa aaaa | Track 4 Step 01 Value (1 - 127) |
| | | -63 - +63 |
| 00 53 | 0aaa aaaa | Track 4 Step 02 Value (1 - 127) |
| | | -63 - +63 |
| 00 54 | 0aaa aaaa | Track 4 Step 03 Value (1 - 127) |
| | | -63 - +63 |
| 00 55 | 0aaa aaaa | Track 4 Step 04 Value (1 - 127) |
| | | -63 - +63 |
| 00 56 | 0aaa aaaa | Track 4 Step 05 Value (1 - 127) |
| | | -63 - +63 |
| 00 57 | 0aaa aaaa | Track 4 Step 06 Value (1 - 127) |
| | | -63 - +63 |
| 00 58 | 0aaa aaaa | Track 4 Step 07 Value (1 - 127) |
| | | -63 - +63 |
| 00 59 | 0aaa aaaa | Track 4 Step 08 Value (1 - 127) |
| | | -63 - +63 |
| 00 5A | 0aaa aaaa | Track 4 Step 09 Value (1 - 127) |
| | | -63 - +63 |
| 00 5B | 0aaa aaaa | Track 4 Step 10 Value (1 - 127) |
| | | -63 - +63 |
| 00 5C | 0aaa aaaa | Track 4 Step 11 Value (1 - 127) |
| | | -63 - +63 |
| 00 5D | 0aaa aaaa | Track 4 Step 12 Value (1 - 127) |
| | | -63 - +63 |
| 00 5E | 0aaa aaaa | Track 4 Step 13 Value (1 - 127) |
| | | -63 - +63 |
| 00 5F | 0aaa aaaa | Track 4 Step 14 Value (1 - 127) |
| | | -63 - +63 |
| 00 60 | 0aaa aaaa | Track 4 Step 15 Value (1 - 127) |
| | | -63 - +63 |
| 00 61 | 0aaa aaaa | Track 4 Step 16 Value (1 - 127) |
| | | -63 - +63 |
|-------------+----------------------------------------------------------------|
| 00 00 00 62 | Total Size |
+------------------------------------------------------------------------------+
❍ Tone AP-Synthesis
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 0aaa | Octave Shift (61 - 67) |
| | | -3 - +3 |
| 00 01 | 0aaa aaaa | Coarse Tune (16 - 112) |
| | | -48 - +48 |
|-------------+-----------+----------------------------------------------------|
| 00 02 | 0aaa aaaa | T-FX Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | Chorus Send Level (0 - 127) |
| 00 04 | 0aaa aaaa | Reverb Send Level (0 - 127) |
| 00 05 | 0000 00aa | Output Assign (0 - 2) |
| | | T-FX, MAIN, DIR |
|-------------+-----------+----------------------------------------------------|
| 00 06 | 0aaa aaaa | Control Assign Dest 1 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 07 | 0000 000a | Control Assign Dest 1 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 08 | 0aaa aaaa | Control Assign Dest 2 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 09 | 0000 000a | Control Assign Dest 2 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 0A | 0aaa aaaa | Control Assign Dest 3 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 0B | 0000 000a | Control Assign Dest 3 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0aaa aaaa | Control Assign Dest 4 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 0D | 0000 000a | Control Assign Dest 4 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 0E | 0aaa aaaa | Control Assign Dest 5 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 0F | 0000 000a | Control Assign Dest 5 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 10 | 0aaa aaaa | Control Assign Dest 6 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 11 | 0000 000a | Control Assign Dest 6 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 12 | 0aaa aaaa | Control Assign Dest 7 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 13 | 0000 000a | Control Assign Dest 7 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 14 | 0aaa aaaa | Control Assign Dest 8 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 15 | 0000 000a | Control Assign Dest 8 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 16 | 0aaa aaaa | Control Assign Dest 9 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 17 | 0000 000a | Control Assign Dest 9 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 18 | 0aaa aaaa | Control Assign Dest 10 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
