13
MIDI Implementation
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 19 | 0000 000a | Control Assign Dest 10 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 1A | 0aaa aaaa | Control Assign Dest 11 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 1B | 0000 000a | Control Assign Dest 11 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 1C | 0aaa aaaa | Control Assign Dest 12 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 1D | 0000 000a | Control Assign Dest 12 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 1E | 0aaa aaaa | Control Assign Dest 13 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 1F | 0000 000a | Control Assign Dest 13 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 20 | 0aaa aaaa | Control Assign Dest 14 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 21 | 0000 000a | Control Assign Dest 14 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 22 | 0aaa aaaa | Control Assign Dest 15 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 23 | 0000 000a | Control Assign Dest 15 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 24 | 0aaa aaaa | Control Assign Dest 16 Source (0 - 108) |
| | | OFF, CC01 - CC31, OFF, CC33 - CC95, BEND, AFT, |
| | | PAD-X, PAD-Y, |
| | | BEAM-L, BEAM-R, KNOB1, KNOB2, |
| | | MOD, SW1, SW2, PEDAL1, PEDAL2 |
| 00 25 | 0000 000a | Control Assign Dest 16 Polarity (0 - 1) |
| | | NORMAL, REVERSE |
|-------------+-----------+----------------------------------------------------|
| 00 26 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 27 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 28 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 29 | 0aaa aaaa | (reserved) (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 2A | 0aaa aaaa | (reserved) (0 - 127) |
| 00 2B | 0aaa aaaa | AP-S Phrase Model (0 - 127) |
| | | |
| 00 2C | 0aaa aaaa | AP-S Level (0 - 127) |
| 00 2D | 0aaa aaaa | AP-S Pan (0 - 127) |
| | | L64 - 63R |
| 00 2E | 0aaa aaaa | AP-S Pitch Fine Tune (14 - 114) |
| | | -50 - +50 |
|-------------+-----------+----------------------------------------------------|
|# 00 2F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 33 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 37 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 43 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 47 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 53 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 57 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 5F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 63 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 67 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 6B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 6F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 73 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 77 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 7B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 20 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 7F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 21 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 03 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 22 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 07 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 23 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 0B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 24 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 25 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 13 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 26 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 17 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 27 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 1B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 28 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 1F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 29 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 23 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 30 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 27 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 31 (12768 - 52768) |
| | | -20000 - +20000 |
|# 01 2B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | AP-S Parameter 32 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 01 2F | Total Size |
+------------------------------------------------------------------------------+
❍ Tone Vocal Designer
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 aaaa | Vocoder Type (1 - 4) |
| | | STEREO, MONO, VINTAGE, EXT-IN |
| 00 01 | 0aaa aaaa | T-FX Send Level (0 - 127) |
| 00 02 | 0aaa aaaa | Chorus Send Level (0 - 127) |
| 00 03 | 0aaa aaaa | Reverb Send Level (0 - 127) |
| 00 04 | 0000 00aa | Output Assign (0 - 2) |
| | | T-FX, MAIN, DIR |
|-------------+-----------+----------------------------------------------------|
| 00 05 | 0000 aaaa | Mic Setting Number (1 - 8) |
|-------------+-----------+----------------------------------------------------|
| 00 06 | 0aaa aaaa | Natural Voice Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 07 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 08 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 09 | 0aaa aaaa | (reserved) (0 - 127) |
| 00 0A | 0aaa aaaa | (reserved) (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 0B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Vocoder Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Vocoder Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 13 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Vocoder Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 17 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Vocoder Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1B | 0000 aaaa | |
| | 0000 bbbb | |
