Roland V-Synth GT Supplementary Guide

16
MIDI Implementation
|# 00 75 | 0000 aaaa | |
| | 0000 bbbb | Env 10 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 00 77 | 0000 aaaa | |
| | 0000 bbbb | Env 10 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 79 | 0aaa aaaa | Env 10 Sustine (0 - 127) |
|# 00 7A | 0000 aaaa | |
| | 0000 bbbb | Env 10 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 7C | 0000 0aaa | Env 10 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 00 7D | 0aaa aaaa | Env 10 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 7E | 0aaa aaaa | Env 10 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 00 7F | 0aaa aaaa | Env 10 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 00 | 0aaa aaaa | Env 10 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 01 | 00aa aaaa | Env 10 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 02 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 04 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 06 | 0aaa aaaa | Env 11 Sustine (0 - 127) |
|# 01 07 | 0000 aaaa | |
| | 0000 bbbb | Env 11 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 09 | 0000 0aaa | Env 11 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 0A | 0aaa aaaa | Env 11 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0B | 0aaa aaaa | Env 11 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0C | 0aaa aaaa | Env 11 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0D | 0aaa aaaa | Env 11 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 0E | 00aa aaaa | Env 11 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 0F | 0000 aaaa | |
| | 0000 bbbb | Env 12 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 11 | 0000 aaaa | |
| | 0000 bbbb | Env 12 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 13 | 0aaa aaaa | Env 12 Sustine (0 - 127) |
|# 01 14 | 0000 aaaa | |
| | 0000 bbbb | Env 12 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 16 | 0000 0aaa | Env 12 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 17 | 0aaa aaaa | Env 12 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 18 | 0aaa aaaa | Env 12 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 19 | 0aaa aaaa | Env 12 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 1A | 0aaa aaaa | Env 12 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 1B | 00aa aaaa | Env 12 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+-----------+----------------------------------------------------|
|# 01 1C | 0000 aaaa | |
| | 0000 bbbb | Env 13 Attack Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
|# 01 1E | 0000 aaaa | |
| | 0000 bbbb | Env 13 Decay Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 20 | 0aaa aaaa | Env 13 Sustine (0 - 127) |
|# 01 21 | 0000 aaaa | |
| | 0000 bbbb | Env 13 Release Time (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 01 23 | 0000 0aaa | Env 13 Velocity Curve (0 - 7) |
| | | FIXED, 1 - 7 |
| 01 24 | 0aaa aaaa | Env 13 Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 25 | 0aaa aaaa | Env 13 Attack Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 26 | 0aaa aaaa | Env 13 Decay Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 27 | 0aaa aaaa | Env 13 Release Velocity Sens (1 - 127) |
| | | -63 - +63 |
| 01 28 | 00aa aaaa | Env 13 Time Keyfollow (44 - 84) |
| | | -200 - +200 |
|-------------+----------------------------------------------------------------|
| 00 00 01 29 | Total Size |
+------------------------------------------------------------------------------+
+-------------------------------+
| Env1 | OSC1 Pitch |
| Env2 | OSC1 Time/Pulse Width |
| Env3 | OSC1 Formant/Fat |
| Env4 | OSC1 Level |
| Env5 | OSC2 Pitch |
| Env6 | OSC2 Time/Pulse Width |
| Env7 | OSC2 Formant/Fat |
| Env8 | OSC2 Level |
| Env9 | COSM1 Parameter 1 |
| Env10 | COSM1 Parameter 2 |
| Env11 | COSM2 Parameter 1 |
| Env12 | COSM2 Parameter 2 |
| Env13 | TVA Level |
+-------------------------------+
❍ Tone LFO
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 0aaa | LFO 1 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 01 | 0000 aaaa | |
| | 0000 bbbb | LFO 1 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 03 | 0000 0aaa | LFO 1 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 04 | 0aaa aaaa | LFO 1 Delay Time (0 - 127) |
| 00 05 | 0000 00aa | LFO 1 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 06 | 0aaa aaaa | LFO 1 Fade Time (0 - 127) |
| 00 07 | 0000 000a | LFO 1 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 08 | 0000 0aaa | LFO 2 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 09 | 0000 aaaa | |
| | 0000 bbbb | LFO 2 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 0B | 0000 0aaa | LFO 2 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 0C | 0aaa aaaa | LFO 2 Delay Time (0 - 127) |
| 00 0D | 0000 00aa | LFO 2 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 0E | 0aaa aaaa | LFO 2 Fade Time (0 - 127) |
| 00 0F | 0000 000a | LFO 2 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 10 | 0000 0aaa | LFO 3 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 11 | 0000 aaaa | |
| | 0000 bbbb | LFO 3 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 13 | 0000 0aaa | LFO 3 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 14 | 0aaa aaaa | LFO 3 Delay Time (0 - 127) |
| 00 15 | 0000 00aa | LFO 3 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 16 | 0aaa aaaa | LFO 3 Fade Time (0 - 127) |
| 00 17 | 0000 000a | LFO 3 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 18 | 0000 0aaa | LFO 4 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 19 | 0000 aaaa | |
| | 0000 bbbb | LFO 4 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 1B | 0000 0aaa | LFO 4 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 1C | 0aaa aaaa | LFO 4 Delay Time (0 - 127) |
| 00 1D | 0000 00aa | LFO 4 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 1E | 0aaa aaaa | LFO 4 Fade Time (0 - 127) |
| 00 1F | 0000 000a | LFO 4 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 20 | 0000 0aaa | LFO 5 Waveform (0 - 7) |
| | | SIN, TRI, SAW, SQR, RND, TRP, |
| | | S&H, CHS |
|# 00 21 | 0000 aaaa | |
| | 0000 bbbb | LFO 5 Rate (0 - 144) |
| | | 0 - 127, MUSICAL-NOTES |
| 00 23 | 0000 0aaa | LFO 5 Offset (0 - 4) |
| | | -100, -50, 0, +50, +100 |
| 00 24 | 0aaa aaaa | LFO 5 Delay Time (0 - 127) |
| 00 25 | 0000 00aa | LFO 5 Fade Mode (0 - 3) |
| | | ON-IN, ON-OUT, OFF-IN, OFF-OUT |
| 00 26 | 0aaa aaaa | LFO 5 Fade Time (0 - 127) |
| 00 27 | 0000 000a | LFO 5 Key Sync (0 - 1) |
| | | OFF, ON |
|-------------+----------------------------------------------------------------|
| 00 00 00 28 | Total Size |
+------------------------------------------------------------------------------+
+--------------+
| LFO1 | OSC1 |
| LFO2 | OSC2 |
| LFO3 | COSM1 |
| LFO4 | COSM2 |
| LFO5 | TVA |
+--------------+
❍ Tone COSM
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | COSM Switch (0 - 1) |
| | | BYPASS, ON |
| 00 01 | 0aaa aaaa | COSM Type (0 - 16) |
| | | |
|-------------+-----------+----------------------------------------------------|
|# 00 02 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 06 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 12 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 16 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 22 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 26 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 32 | 0000 aaaa | |
| | 0000 bbbb | |
