Roland V-Synth GT

17
MIDI Implementation
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | COSM Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 00 42 | Total Size |
+------------------------------------------------------------------------------+
❍ Patch Common
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | Patch Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 01 | 0aaa aaaa | Patch Name 2 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 02 | 0aaa aaaa | Patch Name 3 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 03 | 0aaa aaaa | Patch Name 4 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 04 | 0aaa aaaa | Patch Name 5 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 05 | 0aaa aaaa | Patch Name 6 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 06 | 0aaa aaaa | Patch Name 7 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 07 | 0aaa aaaa | Patch Name 8 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 08 | 0aaa aaaa | Patch Name 9 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 09 | 0aaa aaaa | Patch Name 10 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0A | 0aaa aaaa | Patch Name 11 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 0B | 0aaa aaaa | Patch Name 12 (32 - 127) |
| | | 32 - 127 [ASCII] |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0aaa aaaa | Patch Category (0 - 15) |
|-------------+-----------+----------------------------------------------------|
| 00 0D | 0aaa aaaa | Patch Level (0 - 127) |
| 00 0E | 0aaa aaaa | Patch Coarse Tune (16 - 112) |
| | | -48 - +48 |
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Patch Tempo (200 - 2500) |
| | | 20.0 - 250.0 |
|-------------+-----------+----------------------------------------------------|
| 00 13 | 0000 00aa | (reserved) (0 - 2) |
| 00 14 | 0000 000a | S1 Assign Mode (0 - 1) |
| | | LATCH, MOMENTARY |
| 00 15 | 0000 000a | S2 Assign Mode (0 - 1) |
| | | LATCH, MOMENTARY |
|-------------+-----------+----------------------------------------------------|
| 00 16 | 0000 000a | Chorus Switch (0 - 1) |
| | | OFF, ON |
| 00 17 | 0000 000a | Reverb Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 00 18 | 0000 000a | (reserved) (0 - 1) |
| 00 19 | 0000 00aa | Arpeggio Tone Select (0 - 2) |
| | | UPPER, LOWER, UPPER&LOWER |
| 00 1A | 0000 000a | APM Tone Select (0 - 1) |
| | | UPPER, LOWER |
| 00 1B | 0000 000a | Vocal Designer Tone Select (0 - 1) |
| | | UPPER, LOWER |
|-------------+-----------+----------------------------------------------------|
| 00 1C | 0000 0aaa | Vocal Designer Car/Mod Select (0 - 3) |
| | | NORMAL, CAR-BY-OTHERTONE, |
| | | MOD-BY-OTHERTONE, PROCESSOR |
|-------------+-----------+----------------------------------------------------|
| 00 1D | 0aaa aaaa | (reserved) (0 - 127) |
| 00 1E | 0aaa aaaa | (reserved) (0 - 127) |
| 00 1F | 0aaa aaaa | (reserved) (0 - 127) |
| 00 20 | 0aaa aaaa | (reserved) (0 - 127) |
|-------------+----------------------------------------------------------------|
| 00 00 00 21 | Total Size |
+------------------------------------------------------------------------------+
❍ Patch Chorus
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 aaaa | Chorus Type (0 - 8) |
| | | |
| 00 01 | 0aaa aaaa | Chorus Master Level (0 - 127) |
| 00 02 | 0aaa aaaa | Chorus Reverb Send Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 03 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 07 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 13 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 17 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 23 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 27 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2B | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2F | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Chorus Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|-------------+----------------------------------------------------------------|
| 00 00 00 33 | Total Size |
+------------------------------------------------------------------------------+
❍ Patch Reverb
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 aaaa | Reverb Type (0 - 13) |
| | | |
| 00 01 | 0aaa aaaa | Reverb Master Level (0 - 127) |
|-------------+-----------+----------------------------------------------------|
|# 00 02 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 1 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 06 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 2 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 3 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 0E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 4 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 12 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 5 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 16 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 6 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 7 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 1E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 8 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 22 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 9 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 26 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 10 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 11 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 2E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 12 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 32 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 13 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 36 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 14 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 15 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 3E | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 16 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 42 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 17 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 46 | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 18 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4A | 0000 aaaa | |
| | 0000 bbbb | |
| | 0000 cccc | |
| | 0000 dddd | Reverb Parameter 19 (12768 - 52768) |
| | | -20000 - +20000 |
|# 00 4E | 0000 aaaa | |
