10- Maintenance of mechanical housings:
Shutdown the machine completely (see § 1-1 on page 3)
Change the oil in the various mechanical boxes every year or after 200 hours using
the SAE 140 respecting the following quantities:
Assembly
Housing
(In the direction of travel)
Oil quantity (in litres)
C8
Middle
1.2
Left
2.2
Right
2.2
C10
Middle
1
Left
1.8
Right
1.8
C11
Middle
1.2
Left
2.2
Right
2.2
C12
Middle
1.2
Left
2.2
Right
2.2
C13
Middle
1.2
Left
2.2
Right
2.2
C22
Middle
1.2
Left
2.2
Right
2.2
C23
Middle
1.2
Left
2.2
Right
2.2
TCE
Middle
1.2
Left
2.5
Right
2.2
Exterior transmission
angle
1.2
Beater (x2)
0.8
TCEI
Middle
1.8
Left
1.5
Right
1.8
Exterior transmission
angle
1
Beater (x2)
0.7
Bed
Bed drive casing (right or left
and right)
2.8
Hydraulic unit
Gear pump casing
0.3
Visco 400
