Instruction manual for 150mm system filter holder
The ergonomic design allows a quick and easy installation of lens and holder. The filter holder may be
able to rotate 360 degrees. The filter holder is made of aviation aluminum. All elements were manufac-
tured in CNC process and have a matt black surface finish. All screws are made of copper with a black
nickel plating. This can reduce the influence of stray light on the images.
Including:
• 150 mm filter holder (1x)
• Locating pins* (4x)
• Fastening screws (2x)
Names of Parts:
1. 360 degree rotating lens mount
2. Set screw
3. Lens mount
4. Locating pins*
5. Fixed screw for clips
6. Filter slots
